2SA733 — PNP General Purpose Amplifier
September 2009
2SA733
PNP General Purpose Amplifier
Features
• This device is designed for general purpose amplifier applications
at collector currents to 300 mA.
• Sourced from Process 68.
1
TO-92
1. Emitter 2. Collector 3.Base
Absolute Maximum Ratings*
Symbol
V
CBO
V
CEO
V
EBO
I
C
T
J
, T
STG
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector current
T
A
=25°C unless otherwise noted
Parameter
Value
-60
-50
-5.0
Units
V
V
V
mA
°C
- Continuous
-500
-55 to +150
Operating and Storage Junction Temperature Range
* These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
NOTES:
1) These ratings are based on a maximum junction temperature of 150 degrees C.
2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle
