Ordering number : EN2997C
SB07-03C
Schottky Barrier Diode
30V, 0.7A, Low IR, Single CP
Applications
•
http://onsemi.com
High frequency rectification (switching regulators, converters, choppers)
Features
•
•
•
•
Fast reverse recovery time (trr max=10ns)
Low forward voltage (VF max=0.55V)
Low switching noise
Low leakage current and high reliability due to highly reliable planar structure
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Repetitive Peak Reverse Voltage
Nonrepetitive Peak Reverse Surge Voltage
Average Output Current
Surge Forward Current
Junction Temperature
Storage Temperature
Symbol
VRRM
VRSM
I
O
I
FSM
Tj
Tstg
50Hz sine wave, 1 cycle
Conditions
Ratings
30
35
700
5
-
-55 to +125
-
-55 to +125
Unit
V
V
mA
A
°C
°C
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating
Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability.
Package Dimensions
unit : mm (typ)
7013A-004
2.9
3
0.1
Product & Package Information
• Package
: CP
• JEITA, JEDEC
: SC-59, TO-236, SOT-23, TO-236AB
• Minimum Packing Quantity : 3,000 pcs./reel
SB07-03C-TB-E
0.5
Packing Type: TB
Marking
2.5
1.5
LOT No.
LOT No.
0.5
1
0.95
2
J
0.4
TB
1 : Anode
2 : No Contact
3 : Cathode
CP
0.3
Electrical Connection
3
0.05
1.1
1
2
Semiconductor Components Industries, LLC, 2013
September, 2013
91212 TKIM/O2407SB TIIM AX-9641/33098HA(KT)/D288AT,TS No.2997-1/6
SB07-03C
Electrical Characteristics
at Ta=25°C
Parameter
Reverse Voltage
Forward Voltage
Reverse Current
Interterminal Capacitance
Reverse Recovery Time
Thermal Resistance
Symbol
VR
VF
IR
C
trr
Rth(j-a)1
Rth(j-a)2
IR=300μA
IF=700mA
VR=15V
VR=10V, f=1MHz
IF=IR=100mA, See specified Test Circuit.
420
Mounted in Cu-foiled area of 16mm
×0.2mm
on glass epoxy board
2
Conditions
Ratings
min
30
0.55
80
25
10
typ
max
Unit
V
V
μA
pF
ns
°C / W
°C / W
330
trr Test Circuit
Duty
≤
10%
100mA 100mA
10mA
trr
Package
CP
50Ω
10μs
100Ω
10Ω
--5V
Ordering Information
Device
SB07-03C-TB-E
Shipping
3,000pcs./reel
memo
Pb Free
5
3
2
IF -- VF
5
2
1000
5
2
100
5
2
10
5
2
1.0
5
2
0.1
0
IR -- VR
5
°
C
Ta=12
Reverse Current, IR --
μA
Forward Current, IF -- A
1.0
7
5
3
2
100
°
C
75
°
C
50
°
C
25
°
C
25
°
C
Ta=
1
0.1
7
5
3
2
0.01
0
25
°
C
0.2
0.4
0.6
0.8
1.0
1.2
ID00383
5
10
15
20
25
30
35
ID00384
Forward Voltage, VF -- V
Average Forward Power Dissipation, PF(AV) -- W
1.0
PF(AV) -- IO
Reverse Voltage, VR -- V
2
C -- VR
Interminal Capacitance, C -- pF
0.8
(1)Rectangular wave
θ
=60
°
(2)Rectangular wave
θ
=120
°
(3)Rectangular wave
θ
=180
°
(4)Sine wave
θ
=180
°
Rectangular
wave
θ
360°
f=1MHz
100
7
5
3
2
0.6
(4)
(2)
(3)
0.4
(1)
Sine
wave
0.2
180°
0
0
0.2
0.4
0.6
0.8
360°
1.0
1.2
ID00385
10
7
5
3
1.0
2
3
5
7
10
2
3
5
7
Average Output Current, IO -- A
Reverse Voltage, VR -- V
ID00386
No.2997-2/6
