VOIDLESS-HERMETICALLY-SEALED
STANDARD RECOVERY GLASS
Qualified per MIL-PRF-19500/286
DEVICES
LEVELS
1N4245 thru 1N4249
JAN
JANTX
JANTXV
DESCRIPTION
“A” Package
This “standard recovery” rectifier diode series is military qualified to MIL-PRF-19500/286
and is ideal for high-reliability applications where a failure cannot be tolerated. These
industry-recognized 1.0 Amp rated rectifiers for working peak reverse voltages from 200 to
1000 volts are hermetically sealed with voidless-glass construction using an internal
“Category I” metallurgical bond. These devices are similar in ratings to the 1N5614 thru
1N5622 series where surface mount MELF package configurations are available by adding a
“US” suffix (see separate data sheet for 1N5614US thru 1N5622US). Microsemi also offers
numerous other rectifier products to meet higher and lower current ratings with various
recovery time speed requirements including fast and ultrafast device types in both through-
hole and surface mount packages.
IMPORTANT:
For the most current data, consult
MICROSEMI’s
website:
http://www.microsemi.com
FEATURES
Popular JEDEC registered 1N4245 to 1N4249 series
Voidless hermetically sealed glass package
Internal “Category
I”
Metallurgical bonds
Working Peak Reverse Voltage 200 to 1000 Volts.
JAN, JANTX, and JANTXV available per MIL-PRF-19500/286 (for JANS, see
1N5614-5622 series)
Surface mount equivalents also available in a square end-cap MELF configuration with
“US” suffix (see separate data sheet for 1N5614US thru 1N5622US)
T4-LDS-LDS-0191 Rev. 2 (110430)
Page 1 of 5
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
APPLICATIONS / BENEFITS
Standard recovery 1 Amp rectifiers 200 to 1000 V
Military and other high-reliability applications
General rectifier applications including bridges, half-bridges, catch diodes, etc.
High forward surge current capability
Extremely robust construction
Low thermal resistance
Controlled avalanche with peak reverse power capability
Inherently radiation hard as described in Microsemi MicroNote 050
MAXIMUM RATINGS
Junction & Storage Temperature: -65
o
C to +175
o
C
Thermal Resistance: 42
o
C/W junction to lead at 3/8 inch (10 mm) lead length from body
Thermal Impedance: 4.5
o
C/W @ 10 ms
Average Rectified Forward Current (I
O
): 1.0 Amps @ T
A
= 55ºC
Forward Surge Current: 25 Amps @ 8.3 ms half-sine
Solder Temperatures: 260ºC for 10 s (maximum)
MECHANICAL AND PACKAGING
CASE: Hermetically sealed voidless hard glass with Tungsten slugs
TERMINATIONS: Axial leads are copper with Tin/Lead (Sn/Pb) finish
MARKING: Body paint and part number, etc.
POLARITY: Cathode band
TAPE & REEL option: Standard per EIA-296
WEIGHT: 340 mg
See package dimensions on last page
T4-LDS-LDS-0191 Rev. 2 (110430)
Page 2 of 5
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
ELECTRICAL CHARACTERISTICS @ 30oC Case Temperature
WORKING
PEAK
REVERSE
VOLTAGE
V
RWM
VOLTS
1N4245
1N4246
1N4247
1N4248
1N4249
200
400
600
800
1000
MINIMUM
AVERAGE
BREAKDOWN RECTIFIED
VOLTAGE
CURRENT
V
BR
@ 100μA
VOLTS
240
480
720
960
1150
I
O
@ T
A
= 55
o
C
AMPS
55 C
1.00
1.00
1.00
1.00
1.00
1.3
1.3
1.3
1.3
1.3
o
TYPE
MAXIMUM
FORWARD
VOLTAGE
V
F
@ 3A
VOLTS
MAXIMUM
REVERSE
CURRENT
I
R
@ V
RWM
μA
25 C
1.0
1.0
1.0
1.0
1.0
o
MAXIMUM
SURGE
CURRENT
(NOTE 1)
I
FSM
AMPS
MAXIMUM
REVERSE
RECOVERY
(NOTE 2)
t
rr
μSec.
5.0
5.0
5.0
5.0
5.0
150 C
150
150
150
150
150
25
25
25
25
25
o
NOTE 1:
I
O
= 1A, 8 ms surge
NOTE 2:
I
F
= 0.5A, I
RM
= 1A, I
R(REC)
= .250A
T4-LDS-LDS-0191 Rev. 2 (110430)
Page 3 of 5
TECH
HNICA DA
AL ATA SH
HEET
6 La Street, Lawren MA 01841
ake
nce,
1-80
00-446-1158 / (978 620-2600 / Fax: (978) 689-0803
8)
:
Web
bsite: http://www.microsemi.com
Gort Road Business P
t
Park, Ennis, Co. C
Clare, Ireland
Tel: +353 (0) 65 6840
0044 Fax: +353 ( 65 6822298
(0)
GRAPHS
S
FIGURE 1
F
TYPICA FORWAR CONDUC
AL
RD
CTANCE CUR
RVE
SYMBO & DEFI
OLS
INITIONS
Symbol
V
BR
V
RWM
V
F
I
R
t
rr
Defi
inition
Minimum Breakdown V
m
Voltage: The minimum vo
e
oltage the dev will exhi at a specif current.
vice
ibit
fied
Working Peak Reverse Voltage: Th maximum p
P
e
he
peak voltage that can be ap
pplied over th operating
he
temperatu range.
ure
Maximum Forward Vo
m
oltage: The m
maximum forw
ward voltage t device wi exhibit at a specified
the
ill
current.
Maximum Leakage Cu
m
urrent: The m
maximum leak
kage current th will flow at the specifie voltage
hat
ed
and tempe
erature.
Reverse Recovery Tim The time i
R
me:
interval betwe the instan the current passes throug zero
een
nt
gh
when chan
nging from th forward dir
he
rection to the reverse direc
ction and a spe
ecified recove decay
ery
point after a peak rever current is r
r
rse
reached.
T4-L
LDS-LDS-0191 Rev. 2 (110430
1
0)
Page 4 of 5
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
PACKAGE DIMENSIONS
NOTE:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Dimension BD shall be measured at the largest diameter.
4. The BL dimension shall include the entire body including slugs and
sections of the leads over which the diameter is uncontrolled. This
uncontrolled area is defined as the zone between the edge of the
diode body and extending .050 inch (1.27 mm) onto the leads
5. The shape of the body, within the bounds of the dimensions is
optional.
6. In accordance with ASME Y14.5M, diameters are equivalent
to
φx
symbology.
Ltr
BD
BL
LD
LL
Dimensions
Inches
Millimeters Notes
Min Max Min Max
.065 .110 1.65 2.79
.125 .250 3.30 5.21
.027 .032 0.66 0.84
.70 1.30 25.4 38.10
T4-LDS-LDS-0191 Rev. 2 (110430)
Page 5 of 5
