MC10EL57, MC100EL57
5V ECL 4:1 Differential
Multiplexer
Description
The MC10/100EL57 is a fully differential 4:1 multiplexer. By
leaving the SEL1 line open (pulled LOW via the input pulldown
resistors) the device can also be used as a differential 2:1 multiplexer
with SEL0 input selecting between D0 and D1.
The SEL1 is the most significant select line. The binary number
applied to the select inputs will select the same numbered data input
(i.e., 00 selects D0).
Multiple V
BB
outputs are provided for single-ended or AC coupled
interfaces. The V
BB
pin, an internally generated voltage supply, is
available to this device only. For single-ended input conditions, the
unused differential input is connected to V
BB
as a switching reference
voltage. V
BB
may also rebias AC coupled inputs. When used,
decouple V
BB
and V
CC
via a 0.01
mF
capacitor and limit current
sourcing or sinking to 0.5 mA. When not used, V
BB
should be left
open.
The 100 Series contains temperature compensation.
Features
http://onsemi.com
MARKING
DIAGRAMS*
16
16
1
10EL57G
AWLYWW
1
SO−16
D SUFFIX
CASE 751B
16
100EL57G
AWLYWW
1
•
Useful as Either 4:1 or 2:1 Multiplexer
•
V
BB
Output for Single-Ended Operation
•
PECL Mode Operating Range: V
CC
= 4.2 V to 5.7 V
•
•
•
•
A
WL
YY
WW
G
= Assembly Location
= Wafer Lot
= Year
= Work Week
= Pb−Free Package
with V
EE
= 0 V
NECL Mode Operating Range: V
CC
= 0 V
with V
EE
=
−4.2
V to
−5.7
V
Internal Input Pulldown Resistors on All Inputs
Q Outputs Will Default LOW with Inputs Open or at V
EE
Pb−Free Packages are Available*
*For additional marking information, refer to
Application Note AND8002/D.
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 6 of this data sheet.
*For additional information on our Pb−Free strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
©
Semiconductor Components Industries, LLC, 2006
November, 2006
−
Rev. 7
1
Publication Order Number:
MC10EL57/D
MC10EL57, MC100EL57
Table 1. ATTRIBUTES
Characteristics
Internal Input Pulldown Resistor
Internal Input Pullup Resistor
ESD Protection
Human Body Model
Machine Model
Charge Device Model
Value
75 KW
N/A
> 1 kV
> 100 V
> 2 kV
Level 1
Oxygen Index: 28 to 34
UL 94 V−0 @ 0.125 in
109 Devices
Moisture Sensitivity (Note 1)
Flammability Rating
Transistor Count
Meets or Exceeds JEDEC Spec EIA/JESD78 IC Latchup Test
1. For additional Moisture Sensitivity information, refer to Application Note AND8003/D.
V
CC
SEL0 SEL1
16
15
14
Q
13
Q
12
V
BB1
11
V
BB2
V
EE
10
9
Table 3. FUNCTION TABLE
4:1
SEL1*
L
L
H
H
1
D0
2
D0
3
D1
4
D1
5
D2
6
D2
7
D3
8
D3
SEL0*
L
H
L
H
DATA OUT
D0
D1
D2
D3
* Pin will default low when left open.
Figure 1. Logic Diagram and Pinout Assignment
Table 2. PIN DESCRIPTION
PIN
D0−3, D0−3
SEL0,1
Q, Q
V
BB1
, V
BB2
V
CC
V
EE
FUNCTION
ECL Diff Data Inputs
ECL MUX Select Inputs
ECL Data Outputs
Reference Voltage Output
Positive Supply
Negative Supply
http://onsemi.com
2
MC10EL57, MC100EL57
Table 4. MAXIMUM RATINGS
Symbol
V
CC
V
EE
V
I
I
out
I
BB
T
A
T
stg
q
JA
q
JC
T
sol
Parameter
PECL Mode Power Supply
NECL Mode Power Supply
PECL Mode Input Voltage
NECL Mode Input Voltage
Output Current
V
BB
Sink/Source
Operating Temperature Range
Storage Temperature Range
Thermal Resistance (Junction−to−Ambient)
Thermal Resistance (Junction−to−Case)
Wave Solder
Pb
Pb−Free
0 lfpm
500 lfpm
Standard Board
<2 to 3 sec @ 248°C
<2 to 3 sec @ 260°C
SOIC−16
SOIC−16
SOIC−16
Condition 1
V
EE
= 0 V
V
CC
= 0 V
V
EE
= 0 V
V
CC
= 0 V
Continuous
Surge
V
I
V
CC
V
I
V
EE
Condition 2
Rating
8
−8
6
−6
50
100
±
0.5
−40
to +85
−65
to +150
130
75
33 to 36
265
265
Unit
V
V
V
V
mA
mA
mA
°C
°C
°C/W
°C/W
°C/W
°C
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect
device reliability.
Table 5. 10EL SERIES PECL DC CHARACTERISTICS
V
CC
= 5.0 V; V
EE
= 0 V (Note 1)
−40°C
Symbol
I
EE
V
OH
V
OL
V
IH
V
IL
V
BB
V
IHCMR
Characteristic
Power Supply Current
Output HIGH Voltage (Note 5)
Output LOW Voltage (Note 2)
Input HIGH Voltage (Single−Ended)
Input LOW Voltage (Single−Ended)
Output Voltage Reference
Input HIGH Voltage Common Mode
Range (Differential Configuration)
(Note 3)
Input HIGH Current
Input LOW Current
0.5
3920
3050
3770
3050
3.57
2.5
4010
3200
Min
Typ
Max
24
4110
3350
4110
3500
3.7
4.6
4020
3050
3870
3050
3.65
2.5
4105
3210
Min
25°C
Typ
Max
24
4190
3370
4190
3520
3.75
4.6
4090
3050
3940
3050
3.69
2.5
4185
3227
Min
85°C
Typ
Max
24
4280
3405
4280
3555
3.81
4.6
Unit
mA
mV
mV
mV
mV
V
V
I
IH
I
IL
150
0.5
150
0.3
150
mA
mA
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declared
operating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit
values are applied individually under normal operating conditions and not valid simultaneously.
1. Input and output parameters vary 1:1 with V
CC
. V
EE
can vary +0.06 V /
−0.5
V.
2. Outputs are terminated through a 50
W
resistor to V
CC
−
2.0 V.
3. V
IHCMR
min varies 1:1 with V
EE
, V
IHCMR
max varies 1:1 with V
CC
. The V
IHCMR
range is referenced to the most positive side of the differential input
signal. Normal operation is obtained if the HIGH level falls within the specified range and the peak-to-peak voltage lies between V
PP
min and 1 V.
http://onsemi.com
3
MC10EL57, MC100EL57
Table 6. 10EL SERIES NECL DC CHARACTERISTICS
V
CC
= 0 V; V
EE
=
−5.0
V (Note 4)
−40°C
Symbol
I
EE
V
OH
V
OL
V
IH
V
IL
V
BB
V
IHCMR
Characteristic
Power Supply Current
Output HIGH Voltage (Note 5)
Output LOW Voltage (Note 5)
Input HIGH Voltage (Single−Ended)
Input LOW Voltage (Single−Ended)
Output Voltage Reference
Input HIGH Voltage Common Mode
Range (Differential Configuration)
(Note 6)
Input HIGH Current
Input LOW Current
0.5
−1080
−1950
−1230
−1950
−1.43
−2.5
−990
−1800
Min
Typ
Max
24
−890
−1650
−890
−1500
−1.30
−0.4
−980
−1950
−1130
−1950
−1.35
−2.5
−895
−1790
Min
25°C
Typ
Max
24
−810
−1630
−810
−1480
−1.25
−0.4
−910
−1950
−1060
−1950
−1.31
−2.5
−815
−1773
Min
85°C
Typ
Max
24
−720
−1595
−720
−1445
−1.19
−0.4
Unit
mA
mV
mV
mV
mV
V
V
I
IH
I
IL
150
0.5
150
0.3
150
mA
mA
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declared
operating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit
values are applied individually under normal operating conditions and not valid simultaneously.
4. Input and output parameters vary 1:1 with V
CC
. V
EE
can vary +0.06 V /
−0.5
V.
5. Outputs are terminated through a 50
W
resistor to V
CC
−
2.0 V.
6. V
IHCMR
min varies 1:1 with V
EE
, V
IHCMR
max varies 1:1 with V
CC
. The V
IHCMR
range is referenced to the most positive side of the differential input
signal. Normal operation is obtained if the HIGH level falls within the specified range and the peak-to-peak voltage lies between V
PP
min and 1 V.
Table 7. 100EL SERIES PECL DC CHARACTERISTICS
V
CC
= 5.0 V; V
EE
= 0 V (Note 7)
−40°C
Symbol
I
EE
V
OH
V
OL
V
IH
V
IL
V
BB
V
IHCMR
Characteristic
Power Supply Current
Output HIGH Voltage (Note 8)
Output LOW Voltage (Note 8)
Input HIGH Voltage (Single−Ended)
Input LOW Voltage (Single−Ended)
Output Voltage Reference
Input HIGH Voltage Common Mode
Range (Differential Configuration)
(Note 9)
Input HIGH Current
Input LOW Current
0.5
3915
3170
3835
3190
3.62
2.5
3995
3305
Min
Typ
Max
24
4120
3445
4120
3525
3.74
4.6
3975
3190
3835
3190
3.62
2.5
4045
3295
Min
25°C
Typ
Max
24
4120
3380
4120
3525
3.74
4.6
3975
3190
3835
3190
3.62
2.5
4050
3295
Min
85°C
Typ
Max
27
4120
3380
4120
3525
3.74
4.6
Unit
mA
mV
mV
mV
mV
V
V
I
IH
I
IL
150
0.5
150
0.5
150
mA
mA
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declared
operating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit
values are applied individually under normal operating conditions and not valid simultaneously.
7. Input and output parameters vary 1:1 with V
CC
. V
EE
can vary +0.8 V /
−0.5
V.
8. Outputs are terminated through a 50
W
resistor to V
CC
−
2.0 V.
9. V
IHCMR
min varies 1:1 with V
EE
, V
IHCMR
max varies 1:1 with V
CC
. The V
IHCMR
range is referenced to the most positive side of the differential input
signal. Normal operation is obtained if the HIGH level falls within the specified range and the peak-to-peak voltage lies between V
PP
min and 1 V.
http://onsemi.com
4
MC10EL57, MC100EL57
Table 8. 100EL SERIES NECL DC CHARACTERISTICS
V
CC
= 0 V; V
EE
=
−5.0
V (Note 10)
−40°C
Symbol
I
EE
V
OH
V
OL
V
IH
V
IL
V
BB
V
IHCMR
Characteristic
Power Supply Current
Output HIGH Voltage (Note 11)
Output LOW Voltage (Note 11)
Input HIGH Voltage (Single−Ended)
Input LOW Voltage (Single−Ended)
Output Voltage Reference
Input HIGH Voltage Common Mode
Range (Differential Configuration)
(Note 12)
Input HIGH Current
Input LOW Current
0.5
−1085
−1830
−1165
−1810
−1.38
−2.5
−1005
−1695
Min
Typ
Max
24
−880
−1555
−880
−1475
−1.26
−0.4
−1025
−1810
−1165
−1810
−1.38
−2.5
−955
−1705
Min
25°C
Typ
Max
24
−880
−1620
−880
−1475
−1.26
−0.4
−1025
−1810
−1165
−1810
−1.38
−2.5
−955
−1705
Min
85°C
Typ
Max
27
−880
−1620
−880
−1475
−1.26
−0.4
Unit
mA
mV
mV
mV
mV
V
V
I
IH
I
IL
150
0.5
150
0.5
150
mA
mA
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declared
operating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit
values are applied individually under normal operating conditions and not valid simultaneously.
10. Input and output parameters vary 1:1 with V
CC
. V
EE
can vary +0.8 V /
−0.5
V.
11. Outputs are terminated through a 50
W
resistor to V
CC
−
2.0 V.
12. V
IHCMR
min varies 1:1 with V
EE
, V
IHCMR
max varies 1:1 with V
CC
. The V
IHCMR
range is referenced to the most positive side of the differential input
signal. Normal operation is obtained if the HIGH level falls within the specified range and the peak-to-peak voltage lies between V
PP
min and 1 V.
Table 9. AC CHARACTERISTICS
V
CC
= 5.0 V; V
EE
= 0 V or V
CC
= 0 V; V
EE
=
−5.0
V (Note 13)
−40°C
Symbol
f
max
t
PLH
t
PHL
t
SKEW
t
JITTER
V
PP
t
r
t
f
Characteristic
Maximum Toggle Frequency
Propagation
Delay
Input Skew
Cycle−to−Cycle Jitter
Input Swing (Note 14)
Output Rise/Fall Times Q
(20%
−
80%)
150
125
DATA→Q/Q
SEL→Q/Q
D
n
, D
m
to Q
TBD
1000
375
150
125
350
440
Min
Typ
TBD
550
690
100
TBD
1000
375
150
125
360
440
Max
Min
25°C
Typ
TBD
560
690
100
TBD
1000
375
380
460
Max
Min
85°C
Typ
TBD
580
710
100
Max
Unit
GHz
ps
ps
ps
mV
ps
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declared
operating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit
values are applied individually under normal operating conditions and not valid simultaneously.
13. 10 Series: V
EE
can vary +0.06 V /
−0.5
V.
100 Series: V
EE
can vary +0.8 V /
−0.5
V.
14. V
PP
min is minimum input swing for which AC parameters guaranteed. The device has a DC gain of
≈40.
http://onsemi.com
5
京公网安备 11010802033920号
EEWORLD
