Datasheet
2A/1A Variable Output
LDO Regulators
BA00DD0xx series BA00CC0xx series
●General
Description
The BA00DD0xx and BD00CC0xx series are low-saturation regulators available for outputs up to 2A/1A. The output voltage
can be arbitrarily configured using the external resistance. These series of LDO regulators are offered in a broad packaging
lineup.
This IC has a built-in over-current protection circuit that prevents the destruction of the IC due to output short circuits and a
thermal shutdown circuit that protects the IC from thermal damage due to overloading.
●Features
±1% high-precision output voltage (BA00DD0xx)
Low saturation with PNP output
Built-in over-current protection circuit that prevents
the destruction of the IC due to output short circuits
Built-in thermal shutdown circuit for protecting the IC
from thermal damage due to overloading
Built-in over- voltage protection circuit that prevents
the destruction of the IC due to power supply surges
●Key
Specifications
Input Power Supply Voltage:
25V(Max.)
Output voltage type:
Variable
Output current: BA00DD0xx series
2A(Max.)
BA00CC0xx series
1A(Max.)
Shutdown current:
0μA(Typ.)
Operating temperature range:
-40℃ to +125℃
●Applications
Usable in DSP power supplies for DVDs and CDs,
FPDs, televisions, personal computers or any other
consumer device
●Packages
HRP5
TO252-5
TO220CP-V5
TO220FP-5
TO220FP-5(V5)
W (Typ.) x D (Typ.) x H (Max.)
9.395mm x 10.54 mm x 2.005mm
6.50 mm x 9.50 mm x 2.50 mm
10.00 mm x 20.12 mm x 4.60 mm
10.00 mm x 30.50 mm x 4.60 mm
10.00 mm x 31.50 mm x 8.15 mm
HRP5
TO252-5
TO220CP-V5
TO220FP-5
●Ordering
Information
TO220FP-5(V5)
B
Part
Number
A
0
0
x
x
0
W
x
x
x
-
xx
Packaging and forming specification
TR: Embossed tape and reel
(HRP5)
E2: Embossed tape and reel
(TO252-5,TO220CP-V5)
None : Container Tube
(TO220FP-5,TO220FP-5(V5))
V5 :Forming(V5 only)
Output voltage
00:Variable
Output Current
CC0 : 1A
DD0 : 2A
Shutdown
switch
W : Includes
switch
Package
HFP：HRP5
FP
：TO252-5
CP
：TO220CP-V5
T
：TO220FP-5
：TO220FP-5(V5)
●Lineup
Maximum output current (Max.)
1A
2A
Package
TO220FP-5
Tube of 500
TO220CP-V5
Reel of 500
TO252-5
Reel of 2000
TO220FP-5(V5) Tube of 500
TO220CP-V5
Reel of 500
HRP5
Reel of 2000
Orderable Part Number
BA00CC0WT
BA00CC0WCP-V5E2
BA00CC0WFP-E2
BA00CC0WT-V5
BA00DD0WCP-V5E2
BA00DD0WHFP-TR
○Product
structure：Silicon monolithic integrated circuit
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½14½001
○This
product is not designed protection against radioactive rays.
1/17
TSZ02201-0R6R0A600080-1-2
25.July.2013 Rev.002
BA00DD0xx series BA00CC0xx series
●Block
Diagrams / Pin Configurations / Pin Descriptions
[BA00CC0WFP]
[BA00DD0WHFP]
N.C.(TO252-5)
GND(HRP5)
3
Vref
Vcc
2
0.33μF
Datasheet
3
Driver
4
V
OUT
+
22μF
OVP
1
CTL
TSD
Fin
OCP
C(ADJ)
5
GND
R1
R2
TOP VIEW
FIN
1 2 3 4 5
1 2 3 4 5
TO252-5
HRP5
PINNo.
1
2
3
4
5
FIN
Symbol
CTL
V
CC
N.C./GND
OUT
C
GND
Function
Output voltage ON / OFF control
Power supply voltage input
Unconnected terminal/GND*
Voltage output
Output voltage regulation terminal
GND
*
TO252-5 is N.C., and HRP5 is GND
[BA00CC0WT] [BA00CC0CP-V5] [BA00DD0WCP-V5] [BA00DD0WCP-V5]
Vref
Vcc
2
0.33μF
Driver
4
V
OUT
+
22μF
OVP
1
CTL
TSD
3
OCP
C(ADJ)
R1
5
GND
R2
TOP VIEW
PINNo. Symbol
Function
1
CTL Output voltage ON/OFF control
2
V
CC
Power supply voltage input
3
GND GND
4
OUT Voltage output
5
ADJ Output voltage regulation terminal
1 2 3 45
1 2 3 45
TO220FP-5
TO220FP-5(V5)
12 3 4 5
TO220CP-V5
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
2/17
TSZ02201-0R6R0A600080-1-2
25.July.2013 Rev.002
BA00DD0xx series BA00CC0xx series
●Absolute
Maximum Ratings (Ta=25℃)
Parameter
Input Power Supply Voltage
*1
Datasheet
Symbol
Vcc
Power Dissipation
*2
Pd
Limits
-0.3 to +35
2300(HRP5)
1300(TO252-5)
2000(TO220FP-5)
2000(TO220FP-5(V5))
2000(TO220CP-V5)
-40 to +125
-55 to +150
+150
-0.3 to +Vcc
+50
Unit
V
mW
Operating Temperature Range
Ambient Storage Temperature
Junction Temperature
Output Control Terminal Voltage
Voltage Applied to the Tip
*3
*1
*2
Topr
Tstg
Tjmax
V
CTL
Vcc peak
℃
℃
℃
V
V
*3
Must not exceed Pd
HRP5 : In cases in which Ta≥25℃ when a 70mm×70mm×1.6mm glass epoxy board is used, the power is reduced by 18.4 mW/℃.
TO252-5 : In cases in which Ta≥25℃ when a 70mm×70mm×1.6mm glass epoxy board is used, the power is reduced by 10.4 mW/℃.
TO252FP-5 : No heat sink. When Ta≥25℃, the power is reduced by 16 mW/℃.
Applied voltage: 200msec or less (tr≥1msec)
tr≧1msec
50V
35V
0V
MAX200msec
(Voltage Supply more than 35V)
●Recommended
Operating Ratings (Ta=25℃)
Parameter
Symbol
BA00CC0xx
Input Power Supply Voltage
Vcc
BA00DD0xx
BA00CC0xx
Output Current
Io
BA00DD0xx
Output Control Terminal Voltage
V
CTL
Min.
4.0
3.0
－
－
0
Max.
25.0
25.0
1
2
Vcc
Unit
V
A
V
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
3/17
TSZ02201-0R6R0A600080-1-2
25.July.2013 Rev.002
BA00DD0xx series BA00CC0xx series
●Electrical
Characteristics
BA00CC0xx Series (Unless otherwise specified, Ta=25℃, V
CTL
=5V, Vcc=10V,Io=500mA,Vo=5V Setting)
Limit
Parameter
Symbol
Unit
Conditions
Min.
Typ.
Max.
Shut Down Current
Isd
－
0
10
μA
V
CTL
=0V
－
Bias Current
Ib
2.5
5.0
mA V
CTL
=2V, Io=0mA
Ｃ
Terminal Voltage
Vc
1.200
1.225
1.250
V
Io=50mA
ΔVd
－
Vcc=Vo×0.95
Dropout Voltage
0.3
0.5
V
Peak Output Current
Io
1.0
－
－
A
f=120Hz, ein
※
4
=1Vrms,
Ripple Rejection
R.R.
45
55
－
dB
Io=100mA
－
Line Regulation
Reg.I
20
100
mV Vcc=6→25V
Load Regulation
Reg.L
－
50
150
mV Io=5mA→1A
Temperature Coefficient of
Tcvo
－
±0.02
－
％/℃
Io=5mA,Tj=0℃ to 125℃
Output Voltage
※5
－
－
Output Short Current
Ios
0.40
A
Vcc=25V
ON Mode Voltage
VthH
2.0
－
－
V
ACTIVE MODE, Io=0mA
－
－
OFF Mode Voltage
VthL
0.8
V
OFF MODE, Io=0mA
Input High Current
I
CTL
100
200
300
μA
V
CTL
=5V, Io=0mA
※4
ein : Input Voltage Ripple
※5
Not 100% tested
Datasheet
BA00DD0xx Series (Unless otherwise specified, Ta=25℃, Vcc=8V, V
CTL
=3V, Vo=5.0V setting)
Limit
Parameter
Symbol
Unit
Conditions
Min.
Typ.
Max.
Shut Down Current
Isd
－
0
10
μA
V
CTL
=0V, Io=0mA
Bias Current
Ib
－
0.9
2.0
mA Io=0mA
ADJ pin Voltage
Vadj
1.257
1.270
1.283
V
Io=100½A
ADJ pin Current
※6
Iadj
－
50
－
nA
Io=0mA
Dropout Voltage1
△Vd1
－
0.3
0.5
V
Vcc=0.95×Vo, Io=1A
Dropout Voltage2
△Vd2
－
0.45
0.7
V
Vcc=0.95×Vo, Io=2A
Peak Output Current
Io
2.0
－
－
A
7
f=120Hz, ein
※
=-20dBV,
Ripple Rejection
R.R.
－
55
－
dB
Io=100mA
Line Regulation
Reg.I
－
15
35
mV Vcc=5.7V→25V, Io=200mA
－
Load Regulation
Reg.L
50
100
mV Io=0mA→2A
Temperature Coefficient of
Tcvo
－
±0.02
－
%/℃ Io=5mA, Tj=0℃ to 125℃
Output Voltage
※6
Output Short Current
Ios
－
0.4
－
A
Vcc=25V
－
CTL ON Mode Voltage
Von
2.0
Vcc
V
ACTIVE MODE, Io=0mA
CTL OFF Mode Voltage
Voff
－
－
0.8
V
OFF MODE, Io=0mA
－
CTL Input Current
I
CTL
60
120
μA
V
CTL
=3V, Io=0mA
※6
Not 100% tested
※7
ein=Input Voltage Ripple
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
4/17
TSZ02201-0R6R0A600080-1-2
25.July.2013 Rev.002
BA00DD0xx series BA00CC0xx series
●Typical
Performance Curves
BA00CC0xx (3.3V preset voltage)
(Unless specified otherwise, Vcc=10V, V
OUT
=3.3V preset, V
CTL
=3V, Io=0mA, R
1
=2.2kΩ, and R
2
=6.8kΩ)
Datasheet
[mA]
[V]
Fig.1
Circuit Current
Fig.2
Input Stability
[V]
[V]
Fig.3
Input Stability
（Io=500mA）
Fig.4
Load Stability
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
5/17
TSZ02201-0R6R0A600080-1-2
25.July.2013 Rev.002
