“Stay Connected”
with
®
Strain Relief Bushings
Heyco RDD Lockit Strain Relief Bushings –
Straight-Thru
®
™
Snap onto
Round Cables
for Faster Assembly into
Double D Mounting Holes
–
Semi-Automatic Equipment Available
Fit 3/4˝ Electrical Knock-out Hole
•
Assembly friendly!
Independent of
insertion into the panel, RDD Lockit
™
Strain Reliefs
self-lock
onto the cable.
Preassemble RDD Lockits off line
for final assembly at a later time or
remote location, for lower installed cost!
•
Install easily with fingertip pressure
into a standard round or Double D
hole. No tools required, even for
hand assembly.
•
Protect the lifeline of your electric/
electronic products by absorbing the
forces of push and pull that may be
exerted on the flexible power cord.
Double D design eliminates the
possibility of part rotation under
forces of twist.
•
Multiple panel locking steps secure
Lockit Strain Reliefs into a wide range
of panel thicknesses for a
flush,
finished fit.
•
Heyco’s automated Pre-Assembly
Equipment speeds assembly of the RDD
onto the cable and thus lowers costs
while greatly reducing risk of carpal
tunnel syndrome. See pages 4-15 & 4-16.
•
Consult Heyco for other wire types
and sizes.
•
See page 4-38 for corresponding
Mounting Hole Plugs
which can be used
to fill blank/unused Mounting Holes and
thus allow for a single panel design for
multiple applications.
•
For Double D Mounting Hole Punches,
see page 4-30.
WILL FIT THESE CABLES
UL Type
AWG/
Approximate
Conductors
Size
in.
mm.
See
table
on page
4-10
See
table
on page
4-10
See
table
on page
4-10
PANEL DIMENSIONS
RDD LOCKIT STRAIN RELIEF
Corresponding
Mounting Hole
Thickness
for Faster Assembly
Mounting Hole Plug
Size
PART NO.
DESC.
PART
in.
mm.
in. mm.
Black White
NO.
DESC.
1,6
2,5
3,2
1868 1869
4,0
4,8
1,6
2,5
3,2
1802 1803
4,0
4,8
1,6
2,5
3,2
1880 1881
4,0
4,8
various
.063
.099
.525- 13,5- 1.109 w/ 28,2 w/
.126
.600 15,2 1.000 flats 25,4 flats
.157
.187
.063
.099
.600- 15,2- 1.109 w/ 28,2 w/
.126
.700 17,8 1.000 flats 25,4 flats
.157
.187
.063
.099
.720- 18,3- 1.250 w/ 31,8 w/
.126
.830 21,1 1.125 flats 28,6 flats
.157
.187
RDD 501
2717 DD 1109-1000
RDD 601
various
various
RDD 701
-
consult
Heyco
NEW!
Standard color black. Consult Heyco for white and other colors.
.91
(23,1 mm)
Locking Tab
1.150
(29,2 mm)
1.000
(25,4 mm)
1.20
(30,5 mm)
1.109
(28,2 mm)
MOUNTING HOLE
RDD 501
1.25
(31,8mm)
Locking Tab
1.23
(31,2mm)
1.000
(25,4mm)
1.33
(33,8mm)
1.109
(28,2mm)
MOUNTING HOLE
RDD 601
Locking Tab
1.31
(33,3 mm)
1.31
(33,3 mm)
1.125
(28,6 mm)
1.44
(36,6 mm)
ø 1.250
(31,8 mm)
MOUNTING HOLE
RDD 701
Quick
Specs
4-9
Material
Certifications
Flammability Rating
Temperature Range
Nylon 6/6
Recognized under UL File E15331
Certified by the Canadian Standards Association File 8919
94V-2
-.04°F (-18°C) to 221°F (105°C)
1-800-526-4182 • 732-286-1800 (NJ) • FAX: 732-244-8843 • www.heyco.com
