Resistor Networks
SINGLE-IN-LINE “SIP” RESISTOR NETWORKS
CONFORMAL COATED, LOW PROFILE
LEADED
FEATURES
• CERMET THICK FILM CONSTRUCTION
• LOW PROFILE 5mm (.200" BODY HEIGHT)
• WIDE RANGE OF RESISTANCE VALUES
• HIGH RELIABILITY AT ECONOMICAL PRICING
• 4 PINS TO 13 PINS AVAILABLE
• 6 CIRCUIT TYPES
NRN Series
CHARACTERISTICS
Item
Rated Power per Resistor at 70
o
C
Operating Temperature Range
Resistance Range
Resistance Temperature Coefficient
TC Tracking
Max. Working Voltage
Short Time Overload
Load Life
Mositure Load Life
Temperature Cycle
Soldering Heat Resistance
Vibration
Insulation Resistance
Solderability
Specifications
Comm on/Bussed:
Isolated:
125mW
Series:
Ladder:
Voltage Divider: 75mW
Terminator:
-55 ~ +125
o
C
10Ω ~ 3.3MegΩ (E24 Values)
±100 ppm/
o
C (10Ω ~2MegΩ )
±200 ppm/
o
C (Values> 2MegΩ )
±50 ppm/
o
C
100 V or Rated Power x Resistance, whichever is less
±1% : JIS C-5202 5 5, 2.5 times max. working voltage
for 5 seconds
±3% : JIS C-5202 7.10, 1000 hrs. at 70
o
C with rated
power applied, 1.5 hrs. on and 0.5 hr. off
±3% : JIS C-5202 7.9, 500 hrs. at 40
o
C and 90 ~ 95%
RH with rated power applied, 1.5 hrs. on and 0.5 hr. off
±1% : JIS C-5202 7.4, 5 Cycles of 30 minutes at -25
o
C,
15 minutes at +25
o
C, 30 minutes at +70
o
C and 15
minutes at +25
o
C
±1% : JIS C-5202 6.4, 260±5
o
C for 10±1 seconds, 3mm
from the body
±1% : 12hrs. at max. 20Gs between 10 to 2kHz
10,000 mW min. at 100v
Per MIL-R-83401
100
DERATING RATE (%)
80
60
40
20
0
0
40
70
POWER DERATING CURVE:
For resistors operating in ambient temperatures above 70
o
C, power
rating should be derated in accordance with the curve shown.
80
120
125
140
AMBIENT TEMPERATURE (
o
C)
®
NIC COMPONENTS CORPORATION
70 Maxess Rd., Melville, NY 11747
•
(631)396-7500 FAX (631)396-7575
Resistor Networks
DIMENSIONS (mm)
NRN Series
¦
MAX
¦
L
Max.
¦
¦
5.08 max.
¦
2.54 max.
No. of PINS
4
5
6
7
8
9
10
11
12
13
L max
10.2
12.7
15.3
17.8
20.4
22.9
25.4
28.0
30.5
33.1
LEADED
1
2
3
4
5
6
7
¦ ¦
¦
3.18 +.640
-.000
¦ ¦
0.25
±0.1
0.50
±0.1
¦¦ ¦
2.54
±0.1
¦
¦
¦
max.
1.2
STANDARD CIRCUITS
Fig. 1: BUSSED/COMMON CIRCUIT
Fig. 2: ISOLATED/INDEPENDENT CIRCUIT
Fig. 3: SERIES CIRCUIT
Fig. 4: LADDER CIRCUIT
Fig. 5: VOLTAGE DIVIDER CIRCUIT
Fig. 6: TERMINATION CIRCUIT
R
R
R
R
R
R
R
R
R
R
R
R
R1
R1
R1
R1
R1
R1
R2
R2
R2
R2
R2
R2
2R
2R
2R
2R
2R
2R
R2
R2
R2
R2
R2
R2
PART NUMBERING SYSTEM
NRN
10
C
104
G
XX
T.C. Option
Tolerance Code: G =
±2%,
J =
±5%
Resistance in ohms first 2 digits are significant, third
is no. of zeros, “R” indicates decimal under 10 ohms
Circuit Type: C = Bussed/Common, I = Isolated
S = Series, V = Voltage Divider,
No. of PINS
Terminator Code = See chart, Ladder Code = See chart
Terminator Code
TA
TB
TC
TD
R1/R2
160/240
180/390
220/270
220/330
330/390
330/470
330/680
1.5K/3.3K
3.0K/6.2K
Special
Series
Part Marking Includes:
1.) Number of PINS.
2.) Circuit Type: "1" or "C" = Common/Bussed
"2" or "I" = Isolated
3.) Resistance Value (in ohms).
4.) Resistance Tolerance:
"G" =
±2%
"J" =
±5%
Ladder Code
LA
LB
LC
LD
LS
R/2R
10K/20K
25K/50K
50K/100K
100K/200K
Special
TE
TF
TG
TH
TI
TS
®
NIC COMPONENTS CORPORATION
70 Maxess Rd., Melville, NY 11747
•
(631)396-7500 FAX (631)396-7575
