30-5298ABI datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 30-5298ABI

30-5298ABI: DescriptionModular Connectors / Ethernet Connectors IVORY 2 PORT BOX; CategoryThe connector; File Size79KB，1 Pages; ManufacturerCINCH

Download Datasheet Parametric View All

30-5298ABI Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	30-5298ABI	-	-	View	Buy Now

30-5298ABI Overview

Modular Connectors / Ethernet Connectors IVORY 2 PORT BOX

30-5298ABI Parametric

Parameter Name	Attribute value
Product Category	Modular Connectors / Ethernet Connectors
Manufacturer	CINCH
RoHS	No
USOC Codes	RJ45
Number of Ports	2 Port
Performance Category	Cat 5e
Termination Style	SMD/SMT
Shielding	Unshielded
Color	Ivory
Contact Material	Phosphor Bronze
Contact Plating	Copper
Gender	Female
Housing Material	Acrylonitrile Butadiene Styrene (ABS)
Factory Pack Quantity	10

Preview

Download Datasheet

View All

DRAWING NO.

30-5198ABI-CUST(SEE TABLE I)

REVISIONS

Description:

See Table I

CAT5E,Surface Mount Boxes

PC Board Design,RJ45/110IDC,

EIA 568A &568b Termination

Crimp Tool:

Impedance:

N/A

OFFICIAL RELEASE

08-17-09

Part No:

Application:

2009.09.0

8 09:25:46

+08'00'

Frequency Range: N/A

Material:

Wire

Housing

24-26AWG,Solid wire

ABS,Color See Table I

Phosphor Bronze,Copper Plated

RoHS Compliance: Yes

Technical Detail:

N/A

CONTROLLED DOCUMENT

P/N

30-5198ABW-CUST

Rev

Rel'd Date

SEP 14,09

68.6

2.700 in

TABLE I

P/N

Description

CAT5E PCB SMB,1 PORT,IV

Color

Ivory

White

RJ45

35.6

1.400 in

68.6

2.700 in

30-5198ABI

30-5198ABW CAT5E PCB SMB,1 PORT,WHITE

CUSTOMER COPY

TOLERANCE UNLESS DRAWN BY

OTHERWISE SPECIFIED

BETTY.YU

DECIMALS

CHECKED BY

DATE

08-17-09

DATE

08-17-09

SHEET

1 OF 1

TITLE

Connectivity

Solutions

CAT5E PCB SMB,I PORT,IV

(SEE TABLE I)

DRAWING NO.

DIM OUTLINE

X.X

X.XX

ANGLES

0.5

0.3

0.1

0.5

BETTY.YU

THOMAS

U/M

APPROVED BY DATE

THIS DRAWING WAS PRODUCED BY COMPUTER,

DO NOT SCALE DRAWING OR UPDATE MANUALLY.

30-5198ABI-CUST

(SEE TABLE I)

SIZE
