This document was generated on 08/13/2012
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
87715-9202
Active
PCI Express Card Edge Connector
1.00mm Pitch, PCI Express* Connector, 98 Circuits, Nylon 4/6 Glass-filled, Black
Housing, Phosphor Bronze, 0.38µm Gold Soldertail, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-87715-200 (PDF)
Test Summary TS-87715-207 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
LR19980
E29179
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Low-Halogen
China RoHS
Agency Certification
CSA
UL
General
Product Family
Series
Comments
Component Type
Overview
Product Name
UPC
Edge Card Connectors
87715
PCI 8 lanes
Edgecard to PCB
PCI Express Card Edge Connector
PCI Express*
822348679874
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
(p)ower-(s)ignal Configuration
Circuits (Loaded)
Circuits (maximum)
Durability (mating cycles max)
Entry Angle
Flammability
Keying to Mating Part
Material - Plating Mating
Material - Plating Termination
Net Weight
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Polarized to Mating Part
Temperature Range - Operating
Termination Interface: Style
98s - 0p
98
98
50
Vertical (Top Entry)
94V-0
Yes
Gold
Tin
5.464/g
2.54mm
Yes
Yes
1.60mm
Tray
1.00mm
1.00mm
0.381µm
Yes
-55°C to +85°C
Through Hole
Search Parts in this Series
87715Series
Mates With
PCI Express Card
Electrical
Current - Maximum per Contact
Voltage - Maximum
1.1A
50V AC (RMS)/DC
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
10
Reflow Capable (SMT only)
1
260
