PA0100-S
Datasheet revision 1.0
www.Proto-Advantage.com
LGA-16 Stencil (1 mm pitch, 4.4 x 7.5 mm body)
DIMENSIONS
REF.
A
A2
B
C
D
E
MIN.
mm
TYP.
2.40
5.50
2.50
0.65
0.35
1.00
MAX.
MIN.
inches
TYP.
MAX.
Top View (SMT Footprint)
B
A
C
E
D
A2
(Representative drawing only - not to scale)
1
© 2014 Proto Advantage Inc
Concept to Life Solutions (CTLS) Inc DBA Proto Advantage Inc
