D-Sub Connector Hoods
152-9009-EX, 152-9015-EX, 152-9025-EX, 152-9037-EX
D-Sub Connector Hoods
#4-40 UNC
B±0.25
(B±0.09
A ± .05
(A±0.19)
F±0.38
(F±0.14)
8.5
(0.335)
A ± .05
(A±0.19)
E±0.5
(E±0.019)
D±0.5
(D±0.019)
152-9009-EX, 152-9015-EX, 152-9025-EX, 152-9037-EX
11.4
(0.448)
C±0.5
(C±0.019)
G
H
I
3.6
(0.141)
Dimensions: mm (in.)
(except where noted)
Mouser
Stock No.
152-9009-EX
152-9015-EX
152-9025-EX
152-9037-EX
Shell
Size
DB9
DB15
DB25
DB37
Dimensions:
B
C
D
24.99 12 33.3
33.32 16 32.8
47.04 16 36.5
63.5 16 39.2
mm
E
F
24.6 14
12.6 14.5
23.6 15
25.4 14.5
A
33.8
42.2
56.3
72.7
G
8.5
9.5
11
11
H
12
16
16
15
I
17
21
21
21
SPECIFICATIONS
Type:
Cover/Clamp:
Screws:
Color:
One piece, hinged, unshielded with side snap locks
Polyporpylene
Steel
Black
RoHS Compliant by Exemption
Date Last Revised: 6-9-09
Available from Mouser Electronics
1-800-346-6873 / www.mouser.com
KC-301358
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
