I
ntroduction & Page Contents
Introduction
Amphenol 62IN series connectors are general purpose,
environment resistant , miniature circular connectors with three-
point bayonet coupling and five-key polarisation. Designed to meet
the requirements of MIL-C-26482, Series I solder type, these
connectors are widely used in applications calling for quick
disconnect connectors.
62IN connectors are intermateable and interchangeable with all MIl-
C-26482 connectors, whether solder or crimp type.
These connectors are used worldwide in military and industrial
applications and are available in a variety of sizes, styles and
configurations.
Amphenol 62IN series connectors are also approved to Indian
Defence Standard Joint Services Specifications JSS50813, certified
by the Electronic Components Standardisation Organisation
(LCSO), Bangalore, India.
Content
Introduction
General description
Insert orientations
Key / Keyway orientations
Insert arrangements
Connector styles
Dust covers
Accessories
Back-Shell
Specials and deviations
Ordering 62IN series connectors
1
Page
1
2
3
4
5
6-11
12
13-15
16-18
19
20
G
eneral Description
Amphenol 62IN series miniature circular bayonet-coupled solder connectors meet the most critical
application needs. Design versatility and high reliability performance makes this series ideal for
environmental sealing.
Shell
Shell hardware is manufactured from aluminum alloy and cadmium plated with an olive drab chromate
finish. This finish has excellent conductivity; it is non-reflectiing and corrosion resistant. Black anodised
finish and cadmium-free zinc cobalt plating are also available. For details, contact factory.
Shell styles consist of wall and box mounting receptacles, jam nut receptacles, cable mounting
receptacles and straight plugs. Connectors are available in 9 shell sizes : 8, 10, 12, 14, 1, 18, 20, 22
and 24.
Positive shell-to-shell keying is provided with keys and keyways in a choice of either normal (N) or any
of the preferred alternate positions: W,X,Y and Z. this prevents mismating between shells of different
orientations and overcomes the difficulties associated with rotated inserts and standard key/keyway
orientation. in the latter system, damage to inserts or contacts can result if excessive force is used to
engage non-mating halves.
Insert and grommet
The insert and grommet are moulded from resilient neoprene, offering high dielectric strength and
resistance to oils, gasoline and low temperature. This provides electrical isolation of the contacts in the
insert and excellent moisture sealing.
Contacts
Gold over nickel plated and socket contacts are machined from brass and designed for solder
connections. Industrial version crimp contacts are also available on request.
Specifications
Number of contacts
Operating temperature
Current rating
Contact size
20
16
Rated current
7.5A
13A
Test current
7.5A
13A
Potential drop
55mV
50mV
2 thru 61 in discrete steps
-55
C to +125
C
Voltage rating (max. operating voltage at sea level)
Service rating
I
II
Insulation resistance
Voltage proof
Service rating
I
II
Wire range accomodations
Contact size
20
16
AWG wire size
24, 22 and 20
20, 18 and 16
Test voltage (rms)
1500V
2300V
AC (rms)
600V
1000V
5000 Mohm
2
