High Performance P-Clamps & Omega Clamps
Other Products
Luminus Series
Smart Engineering
VICTREX
®
PEEK
™
Polymer
Overmold Technology
More details on back
Engineered for lean manufacturing, the High Performance P-Clamps and Omega Clamps were developed to
replace and outperform traditional P-Clamps and Saddle Clamps. Featuring an overmold silicone cushion with
VICTREX PEEK polymer, our clamps are completely non-conductive/non-corrosive, lightweight, and very durable.
Benefits at a Glance
Designed for Lean Manufacturing
High Performance Standoffs
More details on back
Lock open & closed feature increases
ease of installation
One piece
hinged design with overmolded grommet
Easily
recognizable labels
makes inspection easy
Uses
standard 10-32 screws
Smart Engineering
Flexible Options
Fuel Resistant
and
High Temperature
resistant rubbers available
Dedicated to
pressurized and unpressurized
areas
Compatible with
tubes up to 2” in diameter
Smaller envelope
than existing metal P-Clamps
Multiple Sizes Available
P-Clamps: 15
Omega Clamps: 20
QuickClips
More details on back
Completely
Non-Corrosive
&
Non-Conductive
Improved
Strength
&
Stability
Lighter
than Traditional P-Clamps by up to 40%
High temperature
resistance
Withstands constant
vibrations and shock loads
Over 50 years experience
in overmold technology
Silicone or Fluorosilicone Cushion
will not come off or slide off
Allows broad range of
variances in wire bundle diameters
VICTREX PEEK Polymer
Overmold Technology
Amphenol Pcd
www.amphenolpcd.com
email: info@amphenolpcd.com
978-624-3400
Technical Specifications
MATERIALS
Polyetheretherketone (PEEK)
per MIL-P-46183
High Performance P-Clamps
Application Example
Securing Wire Bundle
Clamp Base
Overmolding
Silicone Rubber per
ASTM-D-2000
PERFORMANCE
Temperature
Limits
Continuous: - 65°F to 350°F
Excursions: up to 500°F
Flammability
UL94, V0; FAR25.853
Part No.
Size No.
Inner cushion diameter (ØD)
in
cm
0.30
0.56
0.79
1.03
1.27
1.51
1.75
1.99
2.22
2.46
2.70
2.94
3.18
3.41
3.65
in
0.59
0.64
0.71
0.76
0.81
0.85
0.93
0.97
1.02
1.07
1.14
1.18
1.23
1.29
1.35
F
cm
1.51
1.63
1.81
1.93
2.05
2.17
2.35
2.47
2.59
2.71
2.89
3.01
3.13
3.28
3.43
Length (L)
in
1.18
1.27
1.41
1.51
1.60
1.70
1.84
1.93
2.03
2.12
2.26
2.36
2.45
2.58
2.69
cm
2.99
3.22
3.59
3.83
4.07
4.32
4.67
4.91
5.15
5.38
5.75
5.99
6.23
6.55
6.83
in
0.64
0.71
0.81
0.88
0.96
1.05
1.20
1.32
1.39
1.48
1.62
1.76
1.82
1.93
2.05
H
cm
1.62
1.80
2.06
2.25
2.44
2.68
3.05
3.35
3.53
3.76
4.12
4.47
4.63
4.91
5.20
in
0.18
0.18
0.24
0.24
0.24
0.24
0.30
0.30
0.30
0.30
0.36
0.36
0.36
0.40
0.42
T
cm
0.46
0.46
0.61
0.61
0.61
0.61
0.76
0.76
0.76
0.76
0.91
0.91
0.91
1.00
1.07
Weight
ounces
0.14
0.16
0.22
0.24
0.27
0.29
0.38
0.43
0.45
0.48
0.59
0.64
0.67
0.75
0.85
grams
4.08
4.54
6.35
6.80
7.71
8.16
10.89
12.25
12.70
13.61
16.78
18.14
19.05
21.32
24.04
PCL150101
PCL150102
PCL150103
PCL150104
PCL150105
PCL150106
PCL150107
PCL150108
PCL150109
PCL150110
PCL150111
PCL150112
PCL150113
PCL150114
PCL150115
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
0.12
0.22
0.31
0.41
0.50
0.59
0.69
0.78
0.88
0.97
1.06
1.16
1.25
1.34
1.44
Amphenol Pcd
www.amphenolpcd.com
email: info@amphenolpcd.com
978-624-3400
Technical Specifications
MATERIALS
Polyetheretherketone (PEEK)
per MIL-P-46183
High Performance Omega Clamps
Application Example
Power Feeder Separator
Clamp Base
Overmolding
Silicone Rubber per
ASTM-D-2000
PERFORMANCE
Temperature
Limits
Continuous: - 65°F to 350°F
Excursions: up 500°F
Flammability
UL94, V0; FAR25.853
Part No.
Size
No.
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
28
32
Inner cushion diameter (ØD)
in
cm
1.14
1.30
1.45
1.60
1.78
1.96
2.11
2.26
2.41
2.57
2.72
2.87
3.05
3.20
3.38
3.53
3.68
3.84
3.99
4.32
4.95
in
0.78
0.81
0.84
0.89
0.93
0.96
1.00
1.03
1.08
1.11
1.14
1.17
1.22
1.24
1.27
1.30
1.33
1.36
1.39
1.46
1.58
F
cm
1.98
2.06
2.13
2.26
2.36
2.44
2.54
2.62
2.74
2.82
2.90
2.97
3.10
3.15
3.23
3.30
3.38
3.45
3.53
3.71
4.02
Length (L)
in
2.19
2.25
2.31
2.42
2.49
2.56
2.62
2.68
2.79
2.85
2.91
2.97
3.07
3.10
3.17
3.23
3.29
3.35
3.41
3.57
3.82
cm
5.56
5.72
5.87
6.15
6.32
6.50
6.65
6.81
7.09
7.24
7.39
7.54
7.80
7.87
8.05
8.20
8.36
8.51
8.66
9.07
9.70
in
0.91
0.97
1.03
1.14
1.21
1.28
1.34
1.40
1.51
1.57
1.63
1.69
1.79
1.82
1.89
1.95
2.01
2.07
2.13
2.29
2.54
H
cm
2.31
2.46
2.62
2.90
3.07
3.25
3.40
3.56
3.84
3.99
4.14
4.29
4.55
4.62
4.80
4.95
5.11
5.26
5.41
5.82
6.45
in
0.20
0.20
0.20
0.25
0.25
0.25
0.25
0.25
0.30
0.30
0.30
0.30
0.33
0.30
0.30
0.30
0.30
0.30
0.30
0.33
0.33
E
cm
0.51
0.51
0.51
0.64
0.64
0.64
0.64
0.64
0.76
0.76
0.76
0.76
0.84
0.76
0.76
0.76
0.76
0.76
0.76
0.84
0.84
in
1.56
1.62
1.68
1.79
1.86
1.93
1.99
2.05
2.16
2.22
2.28
2.34
2.44
2.47
2.54
2.60
2.66
2.72
2.78
2.91
3.16
C
cm
3.96
4.11
4.27
4.55
4.72
4.90
5.05
5.21
5.49
5.64
5.79
5.94
6.20
6.27
6.45
6.60
6.76
6.91
7.06
7.39
8.03
Weight
ounces
0.32
0.34
0.35
0.43
0.46
0.48
0.50
0.53
0.67
0.70
0.72
0.75
0.80
0.80
0.82
0.85
0.84
0.90
0.91
1.06
1.17
grams
9.07
9.53
9.98
12.32
12.94
13.61
14.06
14.95
19.05
19.96
20.41
21.32
22.68
22.68
23.13
24.04
23.80
25.40
25.85
30.16
33.11
PCL250008
PCL250009
PCL250010
PCL250011
PCL250012
PCL250013
PCL250014
PCL250015
PCL250016
PCL250017
PCL250018
PCL250019
PCL250020
PCL250021
PCL250022
PCL250023
PCL250024
PCL250025
PCL250026
PCL250028
PCL250032
0.45
0.51
0.57
0.63
0.70
0.77
0.83
0.89
0.95
1.01
1.07
1.13
1.20
1.26
1.33
1.39
1.45
1.51
1.57
1.70
1.95
Amphenol Pcd
www.amphenolpcd.com
email: info@amphenolpcd.com
978-624-3400
Additional Information
Installation
Other Products
Luminus Series
Environmentally sealed
Secure, “snap-locking” mechanism
Multiple sizes and configurations
Rugged and lightweight
Easy to use and maintain
Uses standard MIL-C-39029 and
Stamped & Formed contacts
High Performance
P-Clamp
A locking feature keeps
P-Clamp Open
Wire bundle is
inserted
Second Locking Feature
keeps P-Clamp Closed
Screw inserted to complete
installation
Mounting
Surface Mounting
Stacked Surface Mounting
Standoff Mounting
Stacked Standoff Mounting
Product Customization
High Performance Standoffs
VICTREX PEEK
Polymer
Non-Conductive; Non-Corrosive
Lightweight
The High Performance P-Clamps and Omega Clamps can be customized to your specific
requirements.
Options include, but are not limited to:
Fuel
and
High Temperature
Applications
Alternative
Polymers
and
Rubbers
Available
Specific
Diameter
Requirements
Accompanying
Hardware
VICTREX PEEK
polymers make Amphenol Pcd High Performance P-Clamps and Omega Clamps not only
stronger,
but
lighter.
High performance, superior strength VICTREX PEEK polymer is designed to be chemical, radiation, smoke,
and abrasion resistant. Able to withstand temperature as high as 500° F (260° C), VICTREX PEEK enables
Amphenol Pcd to deliver High Performance P-Clamps and Omega Clamps that outperform traditional P-Clamps
and Saddle Clamps.
VICTREX PEEK Polymers provide high-performance, lightweight solutions to a wide variety of markets, including:
QuickClips
Lightweight
Customization available
Strong and Durable
Amphenol Pcd
72 Cherry Hill Drive
Beverly, MA 01915 USA
Email: info@amphenolpcd.com
Tel: 978-624-3400
Aerospace
Defense
Industrial
Medical
Food Processing
Automotive and Transport
Electronics
Semiconductor and Displays
Industrial
CONNECTING PEOPLE & TECHNOLOGY
For full technical information regarding VICTREX PEEK Polymer visit the Victrex website at www.victrex.com
Amphenol Pcd
www.amphenolpcd.com
email: info@amphenolpcd.com
978-624-3400
Rev. C: Jan, 2014
