SDB101
THRU
SDB107
1.0 Amp Single Phase
Bridge Rectifier
50 to 1000 Volts
SDB-1
-
B
Features
•
•
•
•
•
•
•
•
Lead Free Finish/RoHS Compliant(Note 1) ("P" Suffix designates
RoHS Compliant. See ordering information)
Epoxy meets UL 94 V-0 flammability rating
Moisure Sensitivity Level 1
Surface Mount
and Low Profile
Package
UL Recognized File # E165989
Halogen
free available upon request by adding suffix "-HF"
Maximum Ratings
Operating Temperature: -55°C to +150°C
Storage Temperature: -55°C to +150°C
MCC
Part
Number
SDB101
SDB102
SDB103
SDB104
SDB105
SDB106
SDB107
Maximum
Recurrent
Peak Reverse
Voltage
50V
100V
200V
400V
600V
800V
1000V
Maximum
RMS
Voltage
35V
70V
140V
280V
420V
560V
700V
Maximum
DC
Blocking
Voltage
50V
100V
200V
400V
600V
800V
1000V
∼
+
∼
D
C
Device
Marking
SDB101
SDB102
SDB103
SDB104
SDB105
SDB106
SDB107
K
Notch in Case
A
G
E
H
DIMENSIONS
INCHES
MIN
MAX
.316
.335
.245
.255
.040
.060
.360
.410
.102
.130
.003
.013
.195
.205
.038
.047
MM
MIN
8.05
6.20
1.02
9.40
2.60
.076
5.00
1.00
MAX
8.51
6.50
1.50
10.4
3.30
.330
5.20
1.20
NOTE
Electrical Characteristics @ 25°C Unless Otherwise Specified
Average Forward
Current
Peak Forward Surge
Current
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Typical Junction
Capacitance
Typical thermal
Resistance Per
Leg (Note 2 )
Notes:
I
F(AV)
I
FSM
1.0 A
30A
T
A
= 40°C
8.3ms, half sine
DIM
A
B
C
D
E
G
H
K
V
F
1.1V
I
FM
= 1.0A;
T
A
= 25°C
T
A
= 25°C
T
A
=
125°C
Measured at
1.0MHz, V
R
=4.0V
Suggested Solder Pad
Layout
.047”
I
R
10µA
0.5mA
25pF
40
o
C/W
15
o
C/W
.344”
.060”
C
J
R
θJA
R
θJL
.205”
+
-
Case Style
~
1.
High Temperature Solder Exemption Applied, see EU Directive Annex Notes 7
2.
Units mounted on P.C.B with 0.51x0.51"(13x13mm) copper pads
~
Revision: C
www.mccsemi.com
1 of 3
2014/03/05
SDB101 thru SDB107
Figure
1
Typical Forward
Characteristics
20
10
6
4
2
Amps
1
.6
.4
.2
.1
.06
.04
.02
.01
.4
.6
.8
Volts
Instantaneous Forward Current -
Amperesversus
Instantaneous Forward Voltage -
Volts
1.0
1.2
1.4
25°C
100
60
40
20
10
6
4
2
µAmps 1
.6
.4
.2
.1
.06
.04
.02
.01
20
40
60
MCC
Figure
2
Typical Reverse
Characteristics
TM
Mic Commercial
Components
ro
T
J
=25°C
80
Volts
100
120
140
Instantaneous Reverse Leakage Current -
MicroAmperes
ersus
v
Percent Of Rated Peak Reverse Voltage -
Volts
Figure 3
Forward Derating Curve
1.2
60
50
40
30
0.6
Amps
0.4
Amps
20
10
Figure
4
Peak Forward Surge
Current
1.0
0.8
0
0.2
Single Phase, Half Wave
60Hz Resistive or Inductive Load
0
0
25
50
75
100
125
150
1
2
4
6
8 10
Cycles
Peak Forward Surge Current -
Amperesversus
Number Of Cycles At 60Hz -
Cycles
20
40
60 80
100
Average Forward Rectified Current - Ambient Temperature -
qC
www.mccs
emi.com
Revision: C
2 of 3
2014/03/05
MCC
Micro Commercial Components
TM
Ordering Information
Device
(Part Number)-TP
(Part Number)-BP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel;1.5Kpcs/Reel
Bulk;20Kpcs/Ctn
