NJU7663R Overview

PHS MULTI-FUNCTION GaAs MMIC

Preview

Download Datasheet

View All

NJG1701V

PHS MULTI-FUNCTION GaAs MMIC

nGENERAL

DESCRIPTION

NJG1701V is a GaAs multi-function MMIC composed of a

power amplifier, a SPDT switch and a LNA for Japanese PHS

or WLL application. The SSOP20 package is adopted and

effective for downsizing of handsets.

NJG1701V is operated at low voltage with low current and

low distortion PA, low loss switch and low noise and high gain

LNA.

nAPPLICATION

lPHS,

Digital cordless phone

nFEATURES

(Operating frequency f=1.9GHz)

Transmitting Mode Operation

lDrain

Voltage (PA)

lGain

lCurrent

consumption

lGain

variable range

Receiving Mode Operation

lDrain

Voltage (LNA)

lGain

lCurrent

consumption

lNF

lControl

Voltage (SW)

lPackage

nPIN

CONFIGURATION

V Type

(Top View)

nPACKAGE

OUTLINE

NJG1701V

3.0V typ.

32dB typ.

160mA typ. @P

OUT

=20dBm

33dB typ.

3.0 typ.

14dB typ.

2.8mA typ.

2.7dB typ.

2.7V typ.

SSOP20 (Mount Size: 6.4x6.5x1.25mm)

Pin Connection

1.ANT

11.GND

2.GND

12.GND

3.V

SW2

13.V

DD3

4.GND

14.V

DD2

5.V

DD1

15.GND

6.V

GG1

16.LNAOUT

7.V

CONT

17.GND

8.V

GG2

18.EXTIND

9.GND

19.GND

10.PA

20.V

SW1

-1-
