M30-3101446: DescriptionHeaders u0026 Wire Housings 14P SIL VERT PC TAIL SHROUDED TAB HEADER; CategoryThe connector The connector; File Size114KB，1 Pages; ManufacturerHarwin; Websitehttp://www.harwin.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

M30-3101446 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	M30-3101446	-	-	View	Buy Now

M30-3101446 Overview

Headers u0026 Wire Housings 14P SIL VERT PC TAIL SHROUDED TAB HEADER

M30-3101446 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Harwin
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	ROHS COMPLIANT
body width	0.126 inch
subject depth	0.165 inch
body length	0.758 inch
Body/casing type	RECEPTACLE
Connector type	DIP CONNECTOR
Contact to complete cooperation	TIN
Contact completed and terminated	Tin (Sn)
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	20 mΩ
DIN compliance	NO
Dielectric withstand voltage	500VAC V
Filter function	NO
IEC compliance	NO
Insulation resistance	100000000 Ω
insulator material	NYLON
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	M30-310
Plug contact pitch	0.049 inch
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	1
Number of rows loaded	1
Maximum operating temperature	85 °C
Minimum operating temperature	-25 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
polarization key	POLARIZED HOUSING
Rated current (signal)	1 A
Guideline	UL
reliability	COMMERCIAL
Terminal length	0.091 inch
Terminal pitch	1.25 mm
Termination type	SOLDER
Total number of contacts	14
UL Flammability Code	94V-0
