15-97-5121 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 15-97-5121

15-97-5121: DescriptionHeaders u0026 Wire Housings SOCKET 22-28AWG REEL Reel of 6000; CategoryThe connector The connector; File Size39KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

15-97-5121 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	15-97-5121	-	-	View	Buy Now

15-97-5121 Overview

Headers u0026 Wire Housings SOCKET 22-28AWG REEL Reel of 6000

15-97-5121 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Molex
package instruction	LEAD FREE
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Other features	COMPATIBLE CONTACTS: 46083; 45750; 5556, MINI-FIT TPA
subject depth	0.772 inch
body length	1.129 inch
Body/casing type	RECEPTACLE
Connector type	RECTANGULAR POWER CONNECTOR
Contactor design	PREASSEM CONN
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
Contact resistance	5 mΩ
DIN compliance	NO
Durability	30 Cycles
empty shell	NO
Filter function	NO
IEC compliance	NO
maximum insertion force	6.672 N
Minimum insulation diameter	0.035 inch
Insulation resistance	1000000000 Ω
Insulator color	BLACK
insulator material	POLYESTER
MIL compliance	NO
Plug contact pitch	0.165 inch
Match contact row spacing	0.217 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	LATCH
Installation option 2	PLASTIC
Installation type	CABLE
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Options	GENERAL PURPOSE
polarization key	CENTER
Guideline	UL, CSA
reliability	COMMERCIAL
Shell material	POLYESTER
Total number of contacts	12
UL Flammability Code	94V-0
Maximum wire diameter	16 AWG
Minimum wire diameter	28 AWG
Evacuation force-minimum value	3.1136 N
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 07/31/2017

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

Part Number:

Status:

Overview:

Description:

0015975121

Active

Mini-Fit TPA2 Plugs and Receptacles

Mini-Fit® TPA Receptacle Housing, 4.20mm Pitch, Dual Row with Secondary Terminal

Retention, 12 Circuits

Documents:

3D Model

Drawing (PDF)

Product Specification PS-45750-001-001 (PDF)

Product Specification PS-5556-003 (PDF)

Agency Certification

CSA

General

Product Family

Series

Application

Comments

Product Specification TS-30067-001-001 (PDF)

Packaging Specification PK-30067-001-001 (PDF)

RoHS Certificate of Compliance (PDF)

Series image - Reference only

EU ELV

Not Relevant

EU RoHS

China RoHS

Compliant

REACH SVHC

Not Contained Per -

ED/30/2017 (7 July

2017)

Halogen-Free

Status

Not Low-Halogen

Need more information on product

environmental compliance?

Email productcompliance@molex.com

Please visit the Contact Us section for any

non-product compliance questions.

China ROHS

ELV

RoHS Phthalates

Green Image

Not Relevant

Not Contained

LR19980

E29179

Crimp Housings

30067

Power, Wire-to-Board, Wire-to-Wire

Current = 13A max. per circuit when header is mated

to a receptacle loaded with 45750 series terminals

crimped to 16 AWG wire. . See Molex product

specification PS-45750-001 for additional current

derating information.. Connector Position Assurance

Mini-Fit TPA2 Plugs and Receptacles

Mini-Fit® TPA

800754202237

Black

94V-0

Receptacle

None

Yes

Polyester

3.490/g

Bag

4.20mm

-40°C to +105°C

13.0A

N/A

30067-12A2

PK-30067-001-001

Overview

Product Name

UPC

Physical

Breakaway

Circuits (maximum)

Color - Resin

Flammability

Gender

Glow-Wire Compliant

Keying to Mating Part

Lock to Mating Part

Material - Resin

Net Weight

Number of Rows

Packaging Type

Panel Mount

Pitch - Mating Interface

Stackable

Temperature Range - Operating

Electrical

Current - Maximum per Contact

Solder Process Data

Lead-freeProcess Capability

Material Info

Engineering Number

Reference - Drawing Numbers

Packaging Specification

Search Parts in this Series

30067 Series

Mates With

Plug 30068 , Straight Header 30069 , Right

Angle Header 30070 , 44483

Use With

30072 Mini-Fit® TPA Key<br> 30071 Mini-

Fit® CPA Key<br> 5556 Mini-Fit® Female

Crimp Terminal<br> 45750 Mini-Fit® Plus

HCS Crimp Terminal
