174-7000 Series
Connectors
2.54 min.
2.66 max.
174-7000 Series
ø.787
1
3
Fig. A
3 Pin
2
1
2 3
Fig. B
4 Pin
4
1
2
3
Fig. C
5 Pin
4
5
ø.748
Front View
Dimensions (In.)
Specifications:
•
Type: broadcast quality male XLR
•
Housing, screw collar: zinc high-pressure diecasting satin nickel or black chrome
•
Contact base: valox DR48
•
Contacts: brass 3 microns silver plated or .5 microns gold plated
•
Strain relief: santoprene, UL 94 HBN
•
Sealing ring: santoprene, UL 94 HB
•
Chuck: acetal, UL 94 HB
•
Earthing: spring steel, 3 microns silver plate, anti-tarnish
•
Optional identification rings: acetal, UL 94 HB; colors (yellow, brown,
blue, green, red, white, black, and clear)
•
Cable retention: chuck and screw collar
•
Terminals: solder buckets
•
Cable range: ø2.8mm~ø8.0mm
•
Insertion force:
≤20N
Current Wire Cap.
•
Withdrawal force:
≤10N
Mouser
•
Life: 5000 insertions min.
Stock No. Fig. Housing Contacts Rating AWG (pf)
(A)
•
Working voltage: 250VDC or AC peak
•
Test voltage: 1500VAC
A
16
174-7123
Nickel
Silver
12
≤4
•
Contact resistance:
≤3mΩ
max.
174-7124
B
10
Silver
Nickel
16
≤7
•
Temperature range: -30°~+80°C
7.5
174-7125
C
Silver
Nickel
18
≤7
•
Insulation resistance:
≥1GΩ
16
174-7223
A
Black
Silver
12
≤4
174-7224
B
10
Silver
Black
16
≤7
C
7.5
174-7225
Silver
Black
18
≤7
16
174-7133
A
Nickel
Gold
12
≤4
174-7134
B
10
Gold
Nickel
16
≤7
7.5
C
174-7135
Gold
Nickel
18
≤7
A
16
174-7233
Gold
Black
12
≤4
10
174-7234
B
Black
Gold
16
≤7
174-7235
C
7.5
Gold
Black
18
≤7
Connectors
8-
041800
Date:
7-13-98
Quality, Speed, & Service
(800) 346-6873
http://www.mouser.com
