F
E
D
C
B
A
AT ALL TIMES WATER RESISTANT
CONNECTORS NOT IN USE SHOULD
BE COVERED WITH A CONEC WATER
RESISTANT CAP OR WATER TIGHT HOOD.
10,69
+ 0,4
- 0,3
D
n
1,16 (9x)
(5:1)
SEALING
COMPOUND
D
b
2,55
+ 0,25
-0
30,88
+ 0,3
- 0,15
25
+ 0,13
-
16,46
+ 0
- 0,25
0,12
5,78
+ 0,17
- 0,08
SEALING
GASKET
8
+ 0,23
-
0,02
12,8
+ 0,3
- 0,15
b
10°
C
C
15-00629
o
CONEC ABC
4-40 UNC
SEE NOTE 12
4,6
9,4
4-40 UNC
SW 4,8
B
B
c
NOTES:
1. RECOMMENDED SOLDER INSTRUCTION SEE SHEET 2
2. IP RATING: IP 67
3. SEALED TO WITHSTAND PRESSURE UP TO 1,45 PSI
FOR 30 MINUTES AFTER SOLDERING
4. METALSHELL: ZINC DIE CAST; min. 50µin NICKEL PLATING over COPPER
5. INSULATORS: PBT GF UL 94 V-0; BLACK
6. SEALING GASKET: SILICONE; BLUE
7. SEALING COMPOUND: EPOXY RESIN UL 94 V-0; BLACK
8. CONTACTS: COPPER ALLOY; PLATING (SEE PART-NO.):
o
PLEASE ADD 1 for 30µin HARD GOLD over min. 50µin NICKEL
o
PLEASE ADD 3 for GOLD FLASH over NICKEL
SOLDER CUP ACCEPTS CABLE AWG 20
9. HEXLOCKING SCREWS: STAINLESS STEEL
10. RECOMMENDED PANEL CUT-OUT ON SHEET 2
11. RECOMMENDED TORQUE FOR MOUNTING SCREW
35Ncm (3.1 in.LB) / max. 67Ncm (6 in.LB)
12. CONNECTOR IS PART MARKED: 15-00629
o
CONEC ABC (see note 8)
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
30.09.14
appd.
norm
scale:
material:
name
2:1 (5:1)
SEE NOTES
A
A
title:
Lehmenkühler
Fischer
D-SUB FEMALE
9pos. SOLDER CUP
with closed 4-40 UNC thread
dwg no:
DIN-
A3
sh:
1
26.01.15
1xc
2xb
a
Ä5827
Ä5817
Original
24.09.15 Unkrüer
d-old
15.09.15
M.H.
R
15K1A1536
part no:
RoHS compliant
F
E
rev. description
D
date
name
C
15-00629
o
(see note 8)
A
B
F
E
D
C
B
A
c
Solder Instruction
D
D
1. Cable should be prepared for soldering. The cable/wires must be pretinned.
2. Insert cable/wire into solder cup.
3. Operate the soldering iron at 350°C, 50 Watt max. and use a pencil tip.
4. Apply some solder to the solder tip of the soldering iron.
5. Put tip to wire in solder cup.
6. After 1 second bring in solder.
7. Heat for 3 seconds longer. Do not heat contact more than 4 seconds in total.
8. Remove soldering iron.
9. Wait until solder gets rigid again.
10. Do not solder adjacent contacts consecutively,
alternate position within the connector to minimize heat build up.
C
C
RECOMMENDED PANEL CUT-OUT
i
0,26 A
20,5
`
0,1
B
B
11,4
`
0,1
B
n
3,1
`
0,05
(2x)
R3
10°
`
1°
i
0,26 B
,4
`
3
0, 1
25
`
0,1
A
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
30.09.14
appd.
norm
d-old
scale:
material:
name
5:1
SEE SHEET 1
A
A
title:
Lehmenkühler
Fischer
RECOMMENDED PANEL CUT-OUT
D-SUB FEMALE 9pos. SOLDER CUP
with closed 4-40 UNC thread
dwg no:
DIN-
26.01.15
1xc
a
Ä5827
Original
24.09.15 Unkrüer
R
15K1A1536
part no:
A3
sh:
2
A
rev. description
D
date
name
C
SEE SHEET 1
F
E
B
