Listed to UL 1953, Bussmann series PDBs have SCCRs up to 200 kA, and can replace a lower-rated PDB to help achieve higher
control panel SCCRs. Dual-wire rated ports and the use of UL Listed ferrules greatly expand application flexibility. See data
sheet no. 10537 for specific aluminum and copper conductor, ferrule and dual wire ratings.
Max
SCCR*
200
200
200
200
200
200
200
Wire range
Lineside
2/0-#14
2/0-#14
2/0-#14
2/0-#14
350kcmil-#6
350kcmil-#6
350kcmil-#6
Loadside
2/0-#14
#4-#14
1/4-20 x 3/4” stud
#4-#14
#4-#14
#4-#14
1/0-#14
Catalog no.
PDB204-_
PDB220-_
PDB280-_
PDB321-_
PDB323-_
PDB370-_
PDB371-_
Line/load ports
Poles
1, 3
1, 3
1, 3
1, 2, 3
1, 3
1, 3
1, 3
Amps
175
175
175
175
310
310
310
* SCCR contingent on upstream fusing. See data sheet 10537 for overcurrent protective device requirements.
Bussmann series PDBs SCCR levels have been tested with Bussmann series fuses and Eaton circuit breakers. SCCR levels
up to those shown below are possible with the tested fuses and circuit breaker families. See data sheet 10537 for specific
overcurrent protective device and tested SCCR levels.
Catalog no.
PDB204-1, -3
PDB220-1, -3
PDB280-1, -3
PDB321-1, -2, -3
PDB323-1, -3
PDB370-1, -3
PDB371-1, -3
Max SCCR (kA)
200
200
65
200
200
65
200
65
200
65
200
65
Bussmann series fuse and Eaton circuit breaker families
LPJ, LPN-RK, LPS-RK, FRN-R, FRS-R, JJN, JJS, LP-CC, FNQ-R, KTK-R
LPJ, LPN-RK, LPS-RK, FRN-R, FRS-R, JJN, JJS, SC, LP-CC, FNQ-R, KTK-R
EGC, E_C, EGB, E_B, EGE, E_E, EGS, E_S, EGH, E_H
LPJ, LPN-RK, LPS-RK, FRN-R, FRS-R, JJN, JJS, LP-CC, FNQ-R, KTK-R
LPJ, LPN-RK, LPS-RK, FRN-R, FRS-R, JJN, JJS, SC, LP-CC, FNQ-R, KTK-R
EGC, E_C, EGH, E_E, E_H, EGS, E_S, EGE, EGB, E_B
LPJ, LPN-RK, LPS-RK, FRN-R, FRS-R, JJN, JJS, SC, LP-CC, FNQ-R, KTK-R
JGH, J_H, JGE, J_E, JGS, JGC, J_C, JGU, J_U, JGX, J_X
LPJ, LPN-RK, LPS-RK, FRN-R, FRS-R, JJN, JJS, SC, LP-CC, FNQ-R, KTK-R
JGH, J_H, JGE, J_E, JGS, J_S, JGU, J_U, JGX, J_X
LPJ, LPN-RK, LPS-RK, FRN-R, FRS-R, JJN, JJS, SC, LP-CC, FNQ-R, KTK-R
JGH, J_H, JGE, J_E, JGS, J_S, JGC, J_C, JGU, J_U, JGX, J_X
Device type
Fuse
Fuse
Circuit breaker
Fuse
Fuse
Circuit breaker
Fuse
Circuit breaker
Fuse
Circuit breaker
Fuse
Circuit breaker
Tools to help make SCCR compliance easier:
FC
2
Available Fault Current
Calculator
Calculates available fault
current anytime, anywhere.
SCCR Protection Suite
Quickly finds the Eaton
components with the
SCCRs you need.
OSCAR
TM
Online
Compliance Software
Calculates and documents
assembly SCCR for a
control panel.
