Base strip - MCV 1,5/13-GF-3,5-LR - 1818106
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Header, Nominal current: 8 A, Rated voltage (III/2): 160 V, Number of positions: 13, Pitch: 3.5 mm, Color:
green, Contact surface: Tin, Mounting: Wave soldering
The figure shows a 10-position
version of the product
Why buy this product
Well-known mounting principle allows worldwide use
Screwable flange for superior mechanical stability
Automatic locking and intuitive release through Lock and Release operating lever in contrasting color
Vertical connection enables multi-row arrangement on the PCB
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
Note
4046356755085
85366990
Made to Order (non-returnable)
50 STK
Technical data
Dimensions
Length
Pitch
Dimension a
Length of the solder pin
Pin dimensions
Hole diameter
7.25 mm
3.50 mm
42 mm
3.4 mm
0,8 x 0,8 mm
1.2 mm
General
Range of articles
MCV 1,5/..-GF-LR
11/14/2016 Page 1 / 4
https://www.phoenixcontact.com/hq/products/1818106
Base strip - MCV 1,5/13-GF-3,5-LR - 1818106
Technical data
General
Insulating material group
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
Maximum load current
Insulating material
Flammability rating according to UL 94
Color
Number of positions
IIIa
2.5 kV
2.5 kV
2.5 kV
160 V
160 V
250 V
EN-VDE
8A
8A
PBT
V0
green
13
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
EN-VDE
CUL
V0
Environmental Product Compliance
China RoHS
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Drawings
Drilling diagram
4,3
(4,5)
a
3,5
(3,81)
6,9
(7,1)
Dimensional drawing
7,25
a+13,8
(a+14,2)
3
3,4
9,2
3
Ø2,4
Ø1,2
4,3
(4,5)
3,5
(3,81)
a
6,9
(7,1)
11/14/2016 Page 2 / 4
https://www.phoenixcontact.com/hq/products/1818106
Base strip - MCV 1,5/13-GF-3,5-LR - 1818106
Dimensional drawing
5,45
3,68
11,2
7,8
a+14,6
(a+15)
Approvals
Approvals
Approvals
VDE Gutachten mit Fertigungsüberwachung / cULus Recognized / IECEE CB Scheme / EAC
Ex Approvals
Approval details
VDE Gutachten mit Fertigungsüberwachung
Search.aspx 40011723
Nominal current IN
Nominal voltage UN
http://www.vde.com/en/Institute/OnlineService/VDE-approved-products/Pages/Online-
8A
160 V
cULus Recognized http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm E60425-20110128
Nominal current IN
Nominal voltage UN
B
8A
300 V
D
8A
300 V
IECEE CB Scheme
Nominal current IN
Nominal voltage UN
http://www.iecee.org/ DE1-56063-B1B2
8A
160 V
EAC B.01742
