for Scoop-Proof Series 22 Connectors
METAL SHELL SCOOP-PROOF PLUG COVER
How To Order Receptacle Cover
Sample Part Number
Series -
Shell Style
Attachment Type
Shell Size
Dash No.
Attachment Length
290-016
Metal Plug Protective Covers
Geo-Marine
®
Accessories
See Table III
See Table I
1.13 Max
B
Length
A Thread
Knurl Style
Mfr Option
D
Style A
290-016
S
18
03-
6
290-016
= Scoop Proof
See Table II, IV, V or VI, omit for Type SK
In Inches; ± .25 for Rope, ± Link for Chain
Notes:
1. Assembly identified with manufacturer’s name and P/N, space
permitting.
2. Max. diameter mandrel over which assembled ring will rotate freely.
3. If retaining ring is desired, use Tables IV & V (solid) or Table VI (split ring).
4. For terminal lug or type “WS”, use Table II.
5. Material/finish:
Cover, attachment, clevis, hardware - CRES/passivate
O-ring - nitrile/n.a.
C Dia
E
F (Ref)
See Note 2
Style B
Style C
D
Type WS
Slip Knot
Type Sk
© 2014 Glenair, Inc.
Series 22 Geo-Marine
®
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
C-10
E-Mail: sales@glenair.com
for Scoop-Proof Series 22 Connectors
Table I: Dimensions
Dash
No
10
12
14
16
18
20
22
24
A Thread
Class 2A
0.750 -.1P-.1L
0.875 -.1P-.1L
1.000 -.1P-.1L
1.125 -.1P-.1L
1.250 -.1P-.1L
1.375 -.1P-.1L
1.500 -.1P-.1L
1.625 -.1P-.1L
B
Max
0.900 (22.9)
1.025 (26.0)
1.150 (29.2)
1.275 (32.4)
1.525 (38.7)
1.650 (41.9)
1.775 (45.1)
1.900 (48.3)
Table V: Style B Solid Ring
Dimensions
Dash
E Dia
No
±.015
08
0.468
(11.9)
10
0.593
(15.1)
12
13
14
15
16
17
18
19
20
21
22
23
24
25
27
28
29
30
31
32
33
35
36
40
44
48
0.718
0.765
0.844
0.890
0.968
1.015
1.093
1.140
1.203
1.265
1.343
1.453
1.484
1.577
1.640
1.687
1.765
1.890
1.953
1.968
2.077
2.140
2.187
2.406
2.656
3.031
)(18.2)
(19.4)
(21.4)
(22.6)
(24.6)
(25.8)
(27.8)
(29.0)
(30.6)
(32.1)
(34.1)
(36.9)
(37.7)
(40.1)
(41.7)
(42.8)
(44.8)
(48.0)
(49.6)
(50.0)
(52.8)
(54.4)
(55.5)
(61.1)
(67.5)
(77.0)
Table II: Split Ring Dimensions
Dash No.
C Dia.
01
0.125
(3.2)
02
03
04
05
06
WS
0.140
0.167
0.182
(3.6)
(4.2)
(4.6)
Table III: Attachment Type
Sym
B
C
D
E
F
Table Vi: Style C Ring
Dimensions
Dash No
F Dia
50
52
54
56
58
60
62
64
66
68
70
72
74
76
78
80
82
84
86
88
90
92
94
0.425
0.485
0.640
0.750
0.890
1.015
1.095
1.130
1.250
1.350
1.375
1.485
1.625
1.750
1.875
1.980
2.060
2.235
2.310
2.475
2.655
2.810
3.045
(10.8)
(12.3)
(16.3)
(19.1)
(22.6)
(25.8)
(27.8)
(28.7)
(31.8)
(34.3)
(34.9)
(37.7)
(41.3)
(44.5)
(47.6)
(50.3)
(52.3)
(56.8)
(58.7)
(62.9)
(67.4)
(71.4)
(77.3)
H
K
N
R
T
S
SK
U
Attachment
Bead chain, brass, nickel plated,
with terminal
Link chain, brass, nickel plated,
with clevis terminal
Bead chain, CRES, passivated,
with terminal
Link chain, CRES, passivated,
with clevis terminal
Wire rope, nylon jacket w/
terminal
Wire rope, Fluoropolymer jacket
w/terminal
Nylon rope
Attachment omitted
Wire rope, PVC jacket w/terminal
Wire rope, no jacket, w/terminal
#8 Sash chain, CRES, passivated
Nylon rope, (black) with slip
knot
Wire rope, polyurethane jacket
with terminal
0.191
(4.9)
0.197
(5.0)
With Strap
Table IV: Style A Solid Ring
Dimensions
Dash
D Dia
No
±.015
095
100
101
102
103
104
105
205
106
206
107
207
108
308
208
109
209
110
210
111
211
112
113
213
114
214
115
116
117
0.312
0.391
0.516
0.583
0.641
0.708
(7.9)
(9.9)
(13.1)
(14.8)
(16.3)
(18.0)
0.766 (19.5)
0.788 (20.0)
0.896 (22.8)
0.907 (23.0)
1.016
1.025
1.141
1.188
1.203
1.266
1.312
1.391
1.438
1.521
1.536
1.641
1.766
1.812
(25.8)
(26.0)
(29.0)
(30.2)
(30.6)
(32.2)
(33.3)
(35.3)
(36.5)
(38.6)
(39.0)
(41.7)
(44.9)
(46.0)
1.891 (48.0)
1.938 (49.2)
2.078 (52.8)
2.406 (61.1)
2.510 (63.8)
© 2014 Glenair, Inc.
Series 22 Geo-Marine
®
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
C-11
E-Mail: sales@glenair.com
Geo-Marine
®
Accessories
290-016
Metal Plug Protective Covers
C
