This document was generated on 03/02/2012
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0039304037
Active
minifit_jr
4.20mm Pitch Mini-Fit Jr.™ Header, Single Row, Right Angle, with PCB Mounting
Flanges, 3 Circuits, PA Polyamide Nylon 6/6, 94V-2, 0.76µm Gold (Au)
Documents:
3D Model
Drawing (PDF)
Product Specification PS-5556-001 (PDF)
Packaging Specification PK-5569-002 (PDF)
Test Summary TS-5556-002 (PDF)
RoHS Certificate of Compliance (PDF)
image - Reference only
Series
Agency Certification
CSA
TUV
UL
LR19980
R72081037
E29179
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Low-Halogen
China RoHS
General
Product Family
Series
Application
Comments
PCB Headers
5569
Power, Wire-to-Board
Current = 13A max. per circuit when header is mated
to a receptacle loaded with 45750 Mini-Fit® Plus HCS
Crimp Terminal Crimped to 16 AWG wire., See Molex
Product specification PS-5556001 for additional current
de-rating information.
minifit_jr
Mini-Fit Jr.™
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Overview
Product Name
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
No
3
3
Natural
30
No
94V-2
No
No
None
Yes
Brass
Gold
Tin
Nylon
1
Right Angle
Yes
Yes
1.78mm
Bag
4.20mm
4.20mm
0.762µm
2.540µm
Yes
Yes
Search Parts in this Series
5569Series
Mates With
39014030 Receptacle
Shrouded
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Fully
No
No
-40°C to +105°C
Through Hole
Electrical
Current - Maximum per Contact
Voltage - Maximum
13A
600V
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
5
Wave Capable (TH only)
1
240
Material Info
Old Part Number
5569-03A3GS
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
Test Summary
PK-5569-002
PS-5556-001, RPS-5556-004
SDA-5569-03A**
TS-5556-002
This document was generated on 03/02/2012
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
