NJG1551F
800MHz BAND MIXER GaAs MMIC
nGENERAL
DESCRIPTION
NJG1551F is a mixer GaAs MMIC featured low
distortion, high conversion gain and low noise figure.
NJG1551F includes a mixer and a local amplifier,
and ideally suitable for 800MHz band digital mobile
phone handsets.
The very small MTP package is adopted.
nPACKAGE
OUTLINE
NJG1551F
nFEATURES
lLow
voltage operation
lHigh
conversion gain
lHigh
IP3
lLow
noise figure
lPackage
+2.7V
13dB typ. @f
RF
=820MHz, P
LO
=-10dBm, P
RF
=-30dBm
OIP3=12dBm typ. @f
RF1
=820.0MHz, f
RF2
=820.1MHz
P
LO
=-10dBm, P
RF
=-30dBm
IIP3=-1dBm typ. @f
RF1
=820.0MHz, f
RF2
=820.1MHz
P
LO
=-10dBm, P
RF
=-30dBm
5dB typ. @f
RF
=820MHz, P
LO
=-10dBm
MTP6 (Mount Size: 2.8x2.9x1.2mm)
nPIN
CONFIGURATION
F Type
(Top View)
1
6
Pin Connection
1. IFOUT
2. BPC
3. VLO
4. LOIN
5. GND
6. RFIN
2
5
3
4
NOTE :The
portion above shows orientation mark
printed on the package surface.
-1-
NJG1551F
nTYPICAL
CHARACTERISTICS
(Application 1, f
LO
=690MHz)
16
14
Conversion Gain , Noise Figure
vs. LO Power
Gc
IF , IM3 , IM5 vs. RF Power
16
14
0
20
Conversion Gain (dB)
IF , IM3 , IM5 (dBm)
12
10
8
6
4
2
-40
12
10
8
Noise Figure (dB)
IF
-20
-40
NF
6
4
2
IM3
-60
IM5
-30
-20
-10
0
10
-80
-40
-35
-30
-25
-20
-15
-10
-5
0
LO Power (dBm)
Condition
f
IF
=130MHz
f
RF
=820MHz, P
RF
=-30dBm
f
LO
=690MHz
V
MIX
=V
LO
=2.7V
RF Power (dBm)
Condition
f
IF
=130MHz
f
RF1
=820.0MHz
f
RF2
=820.1MHz
f
LO
=690MHz, P
LO
=-10dBm
V
MIX
=V
LO
=2.7V
Input-IP3 vs. LO Power
2
Conversion Gain , Noise Figure , Input-IP3
vs. V
,V
17
16
MIX
LO
6
NF
5
4
3
Conversion Gain (dB)
15
14
IIP3
IIP3 (dBm)
-2
Gc
13
12
11
10
2
-4
IIP3
1
0
-1
-2
-6
-8
-40
-30
-20
-10
0
10
9
1.5
2
2.5
3
3.5
4
4.5
5
LO Power (dBm)
V
MIX
,V
LO
(V)
Condition
f
IF
=130MHz
f
RF1
=820.0MHz, P
RF
=-30dBm
f
RF2
=820.1MHz
f
LO
=690MHz
V
MIX
=V
LO
=2.7V
3IF-IM3
IIP3=
-G
c
2
@P
RF
=-27dBm
Condition
f
IF
=130MHz
f
RF1
=820.0MHz, P
RF
=-30dBm
f
RF2
=820.1MHz
f
LO
=690MHz, P
LO
=-10dBm
3IF-IM3
IIP3=
-G
c
2
@P
RF
=-27dBm
-3-
NF (dB) , IIP3 (dBm)
0
NJG1551F
nTYPICAL
CHARACTERISTICS
(Continued)
16
Conversion Gain , Noise Figure
vs. Temperature
Gc
NF
Input-IP3 vs. Temperature
8
3
2
7
15
Conversion Gain (dB)
Noise Figure (dB)
1
IIP3 (dBm)
14
6
0
-1
-2
-3
-4
-50
IIP3
13
5
12
4
11
3
10
-50
0
50
o
2
100
0
50
o
100
Temperature ( C)
Temperature ( C)
Condition
f
IF
=130MHz
f
RF
=820MHz, P
RF
=-30dBm
f
LO
=690MHz, P
LO
=-10dBm
V
MIX
=V
LO
=2.7V
Condition
f
IF
=130MHz
f
RF1
=820.0MHz, P
RF
=-30dBm
f
RF2
=820.1MHz
f
LO
=690MHz, P
LO
=-10dBm
V
MIX
=V
LO
=2.7V
3IF-IM3
IIP3=
-G
c
2
@P
RF
=-27dBm
Condition
f
IF
=130MHz
f
RF
=820MHz,P
RF
=-30dBm
f
LO
=690MHz
V
MIX
=V
LO
=2.7V
Condition
f
IF
=130MHz
f
RF
=820MHz
f
LO
=690MHz
V
MIX
=V
LO
=2.7V
-4-
