NJG1508F
SPDT SWITCH GaAs MMIC
nGENERAL
DESCRIPTION
NJG1508F is a GaAs SPDT switch MMIC which features
low loss, high isolation and low control current, and ideally
suitable the cellular phone handsets which needs to switch
during two frequency bands.
NJG1508F is operated in the wide frequency range from
50MHz to 3GHz at a low voltage from 2.5V with very small
MTP6 package.
nFEATURES
lSingle
and low control voltage
lLow
insertion loss
lHigh
isolation
lTransmission
power
lLow
control current
lPackage
nPIN
CONFIGURATION
F Type
(Top View)
1
6
Orientation Mark
nPACKAGE
OUTLINE
NJG1508F
+2.5~+5.5V
0.3dB typ. @f=1.0GHz, P
in
=0dBm
27dB typ. @f=1.0GHz, P
in
=0dBm
19dBm max. @f=2.0GHz, V
CTL
=3.0V
1.0uA typ. @f=0.05~2.5GHz, P
in
=10dBm
MTP6 (Mount Size: 2.8x2.9x1.2mm)
2
5
Pin Connection
1.V
CTR1
2.PC
3.V
CTR2
4.P2
5.GND
6.P1
3
4
nTRUTH
TABLE
“H”=V
CTR (H)
, “L”=V
CTR (L)
V
CTR1
V
CTR2
P1-PC
P2-PC
H
L
OFF
ON
L
H
ON
OFF
L
L
Loss=15dB
P1 Return Loss=-3dB
Loss=15dB
P2 Return Loss=-3dB
H
H
Loss=16dB
P1 Return Loss=-2dB
Loss=16dB
P2 Return Loss=-2dB
Note) The values of “Loss” and “Return Loss” are typical values.
