SMT POWER INDUCTORS
Unshielded Drum Core - P0762NL Series
Height:
3.0mm Max
Footprint:
13.0mm x 9.4mm Max
Current Rating:
up to 2.0A
Inductance Range:
10µH to 1000µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
Part
6,7
Number
P0762.103NL
P0762.153NL
P0762.223NL
P0762.333NL
P0762.473NL
P0762.683NL
P0762.104NL
P0762.154NL
P0762.224NL
P0762.334NL
P0762.474NL
P0762.684NL
P0762.105NL
Inductance
@ I
PK
A
DC
(µH ± 20%)
10
15
22
33
47
68
100
150
220
330
470
680
1000
Irated
5
(A)
2.0
1.5
1.3
1.1
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.05
DCR (MAX)
(mΩ)
110
150
230
300
390
660
840
1200
1900
2700
4000
5300
8400
Saturation Current
(A) @
25°C
2.4
2.0
1.6
1.4
1.0
0.9
0.7
0.6
0.5
0.4
0.3
0.2
0.1
Heating Current
(A)
2.0
1.5
1.3
1.1
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
.05
NOTES:
1. The temperature of the component (ambient plus temperature
rise) must be within the specified operating temperature range.
2. Inductance tested at 100kHz, 10mV
RMS
3. Inductance drop = 10% typical at the Saturation Current.
4.
ΔT
= 15°C rise typical at the heating current.
5. The rated current is the lower of the saturation or heating current.
6. Optional Tape & Reel packaging can be ordered by adding a "T" suffix to the part number
(i.e. P0762.103NL becomes P0762.103NLT). Pulse complies to industry standard tape and
reel specification EIA481.
7. The "NL" suffix indicates an RoHS-compliant part number. Non-NL suffixed parts are not
necessarily RoHS compliant, but are electrically and mechanically equivalent to NL versions.
If a part number does not have the "NL" suffix, but an RoHS compliant version is required,
please contact Pulse for availability.
Mechanical
SUGGESTED PAD LAYOUT
.110
2,79
.115
2,92
.290
7,37
.370 MAX
9,40
.118
3,00
Schematic
XXX
.510 MAX
12,95
1
2
.118
3,00
MAX
.004/0,10
Weight
. . . . . . . . 0.8 grams
Tape & Reel
. . . . . 1000/reel
.520
13,21
.945
± .012
24,00
± 0,30
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
USER DIRECTION OF FEED
TAPE & REEL LAYOUT
.380
9,65
.472
12,00
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
17
SPM2007 (11/07)
