T
Features
■
Formerly a
■
■
■
■
■
Applications
■
Mobile phones
■
Cellular phones
■
CTV, VCR, HIC, FDD
M
PL
IA
N
model
High resistance to heat and humidity
Resistance to mechanical shock and
pressure
Accurate dimensions for automatic
surface mounting
Inductance range: 1 to 150 µH
RoHS compliant*
*R
oH
S
CO
22
0
PM1210 Series - Chip Inductor
Electrical Specifications @25 °C
Bourns
Part No.
Inductance
µH
Tol. (%)
Q
Min.
Test
Frequency
(MHz)
SRF
Min.
(MHz)
DCR
Max.
(Ω)
IDC
(mA)
General Specifications
Operating Temperature
................................-40 °C to +125 °C
(Temperature rise included)
Storage Temperature
................................-40 °C to +125 °C
Resistance to Soldering Heat
.............................. 245 °C, 5 seconds
Temperature Rise ..........................20 °C
Rated Current .... Inductance drops 10 %
Materials
Core ..............................................Ferrite
Wire ...........................Enamelled copper
Enclosure............................. Epoxy resin
Terminal Finish ...................................Sn
Packaging ...... 2,000 pcs. per 7-inch reel
Product Dimensions
2.90 ± 0.2
(.114 ± .008)
PM1210-1R0J-RC
PM1210-1R2J-RC
PM1210-1R5J-RC
PM1210-1R8J-RC
PM1210-2R2J-RC
PM1210-2R7J-RC
PM1210-3R3J-RC
PM1210-3R9J-RC
PM1210-4R7J-RC
PM1210-5R6J-RC
PM1210-6R8J-RC
PM1210-8R2J-RC
PM1210-100J-RC
PM1210-120J-RC
PM1210-150J-RC
PM1210-180J-RC
PM1210-220J-RC
PM1210-270J-RC
PM1210-330J-RC
PM1210-390J-RC
PM1210-470J-RC
PM1210-560J-RC
PM1210-680J-RC
PM1210-820J-RC
PM1210-101J-RC
PM1210-121J-RC
PM1210-151J-RC
1
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
20
20
20
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
120
100
85
80
75
70
60
55
50
45
40
35
30
20
20
20
20
20
17
16
15
13
12
11
10
10
8
0.7
0.75
0.85
0.9
1
1.1
1.2
1.3
1.5
1.6
1.8
2
2.1
2.5
2.8
3.3
3.7
5
5.6
6.4
7
8
9
10
11
11
15
400
390
370
350
320
290
260
250
220
200
180
170
150
140
130
120
110
80
70
65
60
55
50
45
40
70
65
2.20 ± 0.2
(.087 ± .008)
0.60 +0.3/-0.0
(.024 +.012/-.000)
3.20 ± 0.4
(.126 ± .016)
0.60 +0.3/-0.0
(.024 +.012/-.000)
Schematic
0.75 +0.2
(.030 +.008)
2.50 ± 0.2
(.098 ± .008)
0.75 +0.2
(.030 +.008)
1.00 ± 0.2
(.039 ± .008)
Asia-Pacific:
Tel: +886-2 2562-4117 • Fax: +886-2 2562-4116
EMEA:
Tel: +36 88 520 390 • Fax: +36 88 520 211
The Americas:
Tel: +1-951 781-5500 • Fax: +1-951 781-5700
www.bourns.com
Recommended Layout
1.9 ~ 2.4
(.075 ~ .094)
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device
performance may vary over time.
Users should verify actual device performance in their specific applications.
1.2 ~ 1.3
(.047 ~ .051)
1.2 ~ 1.3
(.047 ~ .051)
1.6 ~ 2.0
(.063 ~ .079)
DIMENSIONS:
MM
(INCHES)
