DIP Type
SBPSC Coils
11R310½12R817 Series
〈Magnetically
Shielded Type〉
〈Magnetically
Shielded Type〉
［RoHS
Compliant½
［RoHS
Compliant½
●SBPSC-11R310 Series
Inductance
Reted
DC resistance
（μH）
Current
（Ω）
max.
（100kHz.1mA）
（A）
3.80
±20%
10
SBPSC-11R310-100A
36m
3.40
±20%
12
SBPSC-11R310-120A
48m
3.30
±20%
15
SBPSC-11R310-150A
51m
2.85
±20%
22
SBPSC-11R310-220A
87m
2.40
±20%
27
SBPSC-11R310-270A
106m
2.10
±20%
33
SBPSC-11R310-330A
132m
2.05
±20%
39
SBPSC-11R310-390A
141m
1.80
±20%
47
SBPSC-11R310-470A
181m
1.75
±20%
56
SBPSC-11R310-560A
200m
1.65
±20%
68
SBPSC-11R310-680A
221m
1.55
±20%
82
SBPSC-11R310-820A
251m
1.45
±15%
100
SBPSC-11R310-101A
272m
1.40
±15%
120
SBPSC-11R310-121A
299m
1.15
±15%
150
SBPSC-11R310-151A
390m
0.94
±15%
220
SBPSC-11R310-221A
736m
0.88
±15%
270
SBPSC-11R310-271A
839m
0.84
±15%
330
SBPSC-11R310-331A
936m
0.74
±15%
390
SBPSC-11R310-391A
1.20
0.70
±15%
470
SBPSC-11R310-471A
1.40
0.48
±15%
680
SBPSC-11R310-681A
2.00
0.46
±15%
820
SBPSC-11R310-821A
2.30
0.43
±15%
SBPSC-11R310-102A
1000
2.60
Model
Package: Bulk・1,600pcs/box
●SBPSC-12R817 Series
Inductance
Reted
DC resistance
（μH）
Current
（Ω）
max.
（100kHz.1mA）
（A）
4.70
±20%
29m
10
SBPSC-12R817-100A
4.40
±20%
32m
12
SBPSC-12R817-120A
4.20
±20%
35m
15
SBPSC-12R817-150A
3.90
±20%
43m
22
SBPSC-12R817-220A
3.60
±20%
48m
27
SBPSC-12R817-270A
3.50
±20%
52m
33
SBPSC-12R817-330A
3.30
±20%
58m
39
SBPSC-12R817-390A
3.20
±20%
61m
47
SBPSC-12R817-470A
3.10
±20%
66m
56
SBPSC-12R817-560A
2.90
±20%
75m
68
SBPSC-12R817-680A
2.50
±20%
96m
82
SBPSC-12R817-820A
2.40
±15%
0.14
100
SBPSC-12R817-101A
2.20
±15%
0.18
120
SBPSC-12R817-121A
1.65
±15%
0.26
150
SBPSC-12R817-151A
1.40
±15%
0.40
220
SBPSC-12R817-221A
1.30
±15%
0.47
270
SBPSC-12R817-271A
1.20
±15%
0.53
330
SBPSC-12R817-331A
1.15
±15%
0.57
390
SBPSC-12R817-391A
1.10
±15%
0.62
470
SBPSC-12R817-471A
1.00
±15%
0.70
560
SBPSC-12R817-561A
0.90
0.84
680
SBPSC-12R817-681A
±15%
0.80
0.94
820
SBPSC-12R817-821A
±15%
0.70
1.10
SBPSC-12R817-102A
1000
±15%
Model
Package: Bulk・800pcs/box
*The rated current is the lower value of the following two: the DC curent value when the inductance decreases 10% from the initial value , or the DC current
value when the coil's temperature has rose
ΔT=40˚C
●Operating
temperature range: –20 to +105˚C (Incl. coil heat)
Shape and Dimensions
●SBPSC-11R310 Series
●SBPSC-12R817 Series
wind end mark
（ø1.0
notch on the core）
wind end mark
（ø1.0
notch on the core）
12.0 max.
13.5 max.
10.5 max.
5.0±1.0
ø0.6
ø0.65
5.0±1.0
17.0 max.
5.0±0.5
5.0±0.5
[mm]
Choke Coils VOL.08
●All specifications in this catalog and production status of products are subject to change without notice. Prior to the purchase, please contact NEC TOKIN for updated product data.
●Please request for a specification sheet for detailed product data prior to the purchase.
●Before using the product in this catalog, please read "Precautions" and other safety precautions listed in the printed version catalog.
2008.08.29 P0936MCCC10VOL08E
