105-550 CFM Filtered Fan Boxes
XF Series
Description
In a typical cooling arrangement, the filtered fan box pulls air into the enclosures and the
filter grill is used as an air outlet.
The washable aluminum filter grill and the air filter are easily accessible and can be
removed for cleaning.
The filtered fan boxes are available in either 115 VAC or 230 VAC, 50/60 Hz.
Filtered passive ventilation can be provided by an exhaust filter for either convection
cooling or in combination with a fan in forced air cooling.
Standards
UR/CUR/CE approved fan motors.
CSA listed on fan only.
Features
115 VAC or 230 VAC, 50/60 Hz.
12" lead wires.
Exceptionally quiet operation.
Versatile mounting and adaptability.
Heavy-gauge steel construction.
Attractive stainless steel grills.
Shipped with air flow to pressurize. Can be user modified to exhaust.
Aluminum filter is coated with adhesive baffle surfaces for dust and dirt collection. Can be
recoated after cleaning for optimum performance.
Drilling template included.
Note:
One grill and filter are included with each fan package. Normally, an additional
exhaust grill and filter are required for each installation and must be ordered separately.
Accessories
Filter Coat
https://www.hammfg.com/electrical/products/climate/xf
1/2
11/25/2017
105-550 CFM Filtered Fan Boxes (XF Series) - Hammond Mfg.
Filtered Fan Boxes
Free Flow
Air Delivery
Part No.
XF4115
XF4230
XF6115
XF6230
XF10115
XF10230
(CFM)
105
105
220
220
560
560
115
230
115
230
115
230
Volts
RPM
Nominal
3000
3000
3300
3300
1600
1600
Running
Amps
0.18
0.09
0.29
0.15
0.87
0.45
Watts
15
15
33
33
60
60
A
6.13
6.13
7.63
7.63
11.63
11.63
B
7.38
7.38
8.88
8.88
13.00
13.00
C
2.38
2.38
3.00
3.00
4.56
4.56
D
5.63
5.63
7.13
7.13
11.13
11.13
D¹
5.75
5.75
7.25
7.25
11.25
11.25
E
6.38
6.38
7.88
7.88
11.88
11.88
F
4.13
4.13
4.50
4.50
6.88
6.88
G
0.78
0.78
1.34
1.34
2.16
2.16
H
7.00
7.00
8.50
8.50
12.50
12.50
¹ Dimension for mounting and cabinet cutout. Secure sheet metal with #8 hardware.
Exhaust Grill and Filters
Part No.
XFG4
XFG6
XFG10
A
6.13
7.63
11.63
B
7.38
8.88
13.00
D
5.63
7.13
11.13
E¹
6.38
7.88
11.88
F¹
4.13
4.50
6.88
H¹
7.00
8.50
12.50
¹ Dimension for mounting and cabinet cutout. Secure sheet metal with #8 hardware.
Replacement Filters
Part No.
XFF4
XFF6
XFF10
Pkg. Qty.
3
3
3
Data subject to change without notice
© 2017. Hammond Manufacturing Ltd. All rights reserved.
https://www.hammfg.com/electrical/products/climate/xf
2/2
