TAZ Series
PRODUCT SPECIFICATIONS :
Nominal Capacitance @ 120Hz
Capacitance Tolerance (*)
Rated Voltage DC (V
R
)
Category Voltage DC (V
C
)
Surge Voltage (V
S
)
< 85
o
C
< 125
o
C
< 85
o
C
< 125
o
C
Temperature Range
-55
o
C to +125
o
C
35.2µA
8%
50 mOhms
220µA
K = ± 10%
16V
10V
20V
12V
Direct Leakage Current max. @ +25
o
C
Dissipation Factor max. @ 120Hz @ 25
o
C
ESR max. @ 100kHz +25°C
All technical data relates to an ambient temperature of +25°C
AVX reserves the rights to supply higher voltage rating in the same case size, to the same reliability standards
HOW TO ORDER:
TAZ
Type
V
Case
Size
227
K
016
L
ESR
Range
R
S
B
0
8
00
Capacitance Cap. Voltage
Value Tolerance Code
Packaging Conformance
Reliability
s. current
testing
Grade
Weibull
Termination
Level
Drawing And Dimensions
Capacitance value in pF 227 = 220µA
Rated
Voltage
227
16
Polarity
Band
TAZ Series
CASE DIMENSIONS:
millimeters
"L+/-0.20
"W+0.20 -0.10 "H+0.20 -0.10
"A+0.30 -0.20
S min.
W1 +/-0.20
Case
1.3
4.4
3.1
7.3
6.1
3.55
V
TERMINATION FINISH: (^)
ESR RANGE:
0
C/Z
L
9
8
Gold Plated
Hot Solder Dipped
Solder Fused
Std. ESR
Low ESR
RELIABILITY GRADE: (@)
QUALIFICATION: (#)
Z (s)
L
Comm
Z
Weibull
B
C
Non ER
0.1%/1000 Hrs.
0.01%/1000 Hrs.
Std. Conformance Group A
SURGE TEST OPTION: (++)
23
24
45
00
None required
10 cycles, +25°C
10 cycles, -55°C & +85°C
10 cycles, -55°C & +85°C before Weibull
