MS5536C
SMD Gage Pressure Module
SPECIFICATIONS
Pressure range -400 to 1000 mbar
(Optional -1000 to 400 mbar)
0.1 mbar Resolution
Factory Calibrated (coefficients for software
compensation store on-chip)
3-wire serial interface
Low voltage / low power
MS5536C is a family of high-resolution factory calibrated
pressure sensors. The devices include a piezoresistive pressure
sensor and an ADC-Interface IC. The 3-wire serial interface
ensures simple communication with any microcontroller. The
devices provide digital pressure and temperature information as
16-Bit data word each. In addition 64-Bit of individually calibrated
compensation coefficients are stored allowing for a highly
accurate software compensation of process spread and
temperature effects.
The devices have a very low standby current and automatically
enter power down mode after each conversion. The optimum
compromise of refresh rate and average current consumption can
be defined by the application software.
SENSOR SOLUTIONS
/// MS5536C
06/2017
Page 1
MS5536C
SMD Gage Pressure Module
FEATURES
16-Bit ADC Resolution
Supply voltage 2.2 V to 3.6 V
Low supply current
-40°C to +85°C
Small size
No external components required
APPLICATIONS
Medical application
Blood pressure meter
Air flow measurement
HVAC application
BLOCK DIAGRAM
VDD
MCLK
Input MUX
SENSOR
+IN
dig.
Filter
Digital
Interface
ADC
DIN
DOUT
SCLK
-IN
Sensor
Interface IC
SGND
Memory
(PROM)
64 bits
GND
Fig. 1: Block diagram MS5536C
SENSOR SOLUTIONS
/// MS5536C
06/2017
Page 2
MS5536C
SMD Gage Pressure Module
PIN CONFIGURATION
1
2
3
4
5
6
7
14
13
12
11
10
9
8
14
13
12
11
10
9
8
1
2
3
4
5
6
7
Top view
Bottom view
Fig. 2: Pin configuration of MS5536-CPJU, MS5536-CNJU
PIN DESCRIPTION
Pin Name
N/C
VDD
MCLK
DIN
DOUT
SCLK
GND
N/C
N/C
N/C
N/C
N/C
PV
PEN
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Type
P
I
I
O
I
G
Function
Not Connected
Positive Supply Voltage
Master Clock (32.768kHz)
Data Input
Data Output
Serial Data Clock
Ground
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
Negative Programming Voltage
Programming Enable
N
I
NOTE
Pins 13 (PEN) and 14 (PV) are only used by the manufacturer for calibration purposes and should not be connected.
PRESSURE UNIT CONVERSION
mbar
kPa
bar
mm Hg
PSI
atm
mm H
2
O
Inches H
2
O
400.0
1000.0
40.00
100.00
0.4000
1.0000
300.0
750.0
5.801
14.503
0.3947
0.9869
4079
10198
160.57
401.45
SENSOR SOLUTIONS
/// MS5536C
06/2017
Page 3
MS5536C
SMD Gage Pressure Module
ABSOLUTE MAXIMUM RATINGS
Parameter
Supply voltage
Differential Overpressure
CM Overpressure
Storage temperature
Symbol
V
DD
P
diff
P
CM
T
S
Conditions
Min
-0.3
-5
-40
Max
4
5
10
+125
Unit
V
bar
bar
°C
Notes
1, 2
1, 3
1
NOTES
1) Storage and operation in an environment of dry and non-corrosive gases.
2) For a differential sensor, Differential Pressure is the difference of pressure at port 1 minus pressure at port 2.
For a gage sensor Differential Pressure is the difference of pressure at the port minus pressure of the ambient
air.
3) For a differential sensor Common Mode Pressure is the average of the pressure at port 1 and port 2. For a
gage sensor Common Mode Pressure is the average of the pressure at the port and the pressure of the
ambient air.
RECOMMENDED OPERATING CONDITIONS
Parameter
Supply voltage
Supply current,
average (1)
during conversion (2)
standby (no conversion)
Current consumption into MCLK
(3)
Operating pressure range (4)
Operating pressure range (4)
Operating temperature range
Conversion time
External clock signal (5)
Duty cycle of MCLK
Serial data clock
Symbol
V
DD
I
avg
I
sc
I
ss
MCLK = 32.768 kHz
p
p
T
a
t
conv
MCLK
SCLK
Pressure Range P devices
Pressure Range N devices
MCLK = 32.768 kHz
30.000
40/60
32.768
50/50
-400
-1000
-40
Conditions
V
DD
= 3.0 V
4
1
0.1
0.5
1000
400
+85
35
35.000
60/40
500
µA
mA
µA
µA
mbar
mbar
°C
ms
kHz
%
kHz
(Ta = 25 °C, V
DD
= 3.0 V unless noted otherwise)
Min
Typ
Max
Unit
2.2
3.0
3.6
V
+25
NOTES
1) Under the assumption of one conversion every second. Conversion means either a pressure or a temperature
measurement started by a command to the serial interface of MS5536C.
2) During conversion the sensor will be switched on and off in order to reduce power consumption; the total on
time within a conversion is about 2 ms. The current specified is active only during this time.
3) This value can be reduced by switching off MCLK while MS5536C is in standby mode.
4) Positive pressure corresponds to higher pressure at port 1 (nozzle port on plastic cap).
5) It is strongly recommended that a crystal oscillator be used because the device is sensitive to clock jitter. A
square-wave form of the clock signal is a must.
SENSOR SOLUTIONS
/// MS5536C
06/2017
Page 4
MS5536C
SMD Gage Pressure Module
ELECTRICAL CHARACTERISTICS
DIGITAL INPUTS
Parameter
Input High Voltage
Input Low Voltage
Signal Rise Time
Signal Fall Time
Symbol
V
IH
V
IL
t
r
t
f
Conditions
Min
80% V
DD
0% V
DD
Typ
Max
100% V
DD
20% V
DD
Unit
V
V
ns
ns
200
200
DIGITAL OUTPUTS
Parameter
Output High Voltage
Output Low Voltage
Signal Rise Time
Signal Fall Time
Symbol
V
OH
V
OL
t
r
t
f
Conditions
I
source
= 0.6 mA
I
sink
= 0.6 mA
Min
80% V
DD
0% V
DD
(T = -40 °C .. 85 °C V
DD
= 2.2 V .. 3.6 V)
Typ
Max
Unit
100% V
DD
V
20% V
DD
V
200
ns
200
ns
AD-CONVERTER
Parameter
Resolution
Linear Range
Conversion Time
INL
Symbol
Conditions
Min
4'000
MCLK = 32.768 kHz
Within linear range
-5
(T = -40 °C .. 85 °C V
DD
= 2.2 V .. 3.6 V)
Typ
Max
Unit
16
Bit
40'000
LSB
35
ms
+5
LSB
SENSOR SOLUTIONS
/// MS5536C
06/2017
Page 5
