16.00 in
406 mm
USABLE
SPACE
9
TOP VIEW
SECTION A-A
19.06 in
484 mm
USABLE SPACE
18.35 in
466 mm
19" MTG
17.50 in
444 mm
6
8X
21.33 in
542 mm
1
B
9
5
8X
4
8X
Item Number
1
Title
REFK - TOP PANEL
REFK - SIDE PANEL
REFK - BOTTOM PANEL
NUT 1/4-20 KEP
SCREW 1/4-20 X 1/2
FLAT NYLON WASHER 1/4" I.D.
SCREW 6-32X1/4 SELF TAPPING
REFK - GLAND PLATE
COMBINATION RAILS TAPPED (PAIR)
Quantity
1
2
1
8
8
8
6
1
2
35.00 in
889 mm
(20U)
2
40.19 in
1021 mm
2
3
4
5
6
7
8
9
6X
7
A
REAR VIEW
8
A
L.S. VIEW
B
FRONT VIEW
SECTION B-B
PART NUMBERS
REFK1903517BK1 PAINTED BLACK TEXTURED
REFK1903517CG1 PAINTED CONT. GRAY TEXTURED
REFK1903517LG1 PAINTED RAL7035 TEXTURED
NOTES
Shipped knockdown for handling ease & protection.
.00 in
0 mm
1.21 in
31 mm
1.42 in
36 mm
2.09 in
53 mm
2.93 in
74 mm
3.59 in
91 mm
3
5/16-18 THRU
DETAIL C
.00 in
0 mm
1.18 in
30 mm
1.40 in
35 mm
2.06 in
52 mm
2.90 in
74 mm
3.56 in
90 mm
Data subject to change without notice. Isometric drawing not to scale.
O
4X
.28 in
7 mm
BOTTOM VIEW
DETAIL C
www.hammondmfg.com
PART NO. REFK1903517
