PART
NAME
NBF SERIES PLASTIC NEMA BOX
FLAMMABILITY RATING
UL94-HB
UL94-V0 UV STABLILIZED
UL94-5VA
UL94-5VA + UV (f1)
5.118in
130.00mm
3.150in
80.00mm
CONTINUOUS OPERATING TEMP.
-40 C ~ +60 C / -40 F ~ 140 F
-40 C ~ +130 C / -40 F ~ 266 F
-40 C ~ +85 C / -40 F ~ 185 F
-40 C ~ +75 C / -40 F ~ 167 F
PART
No.
NBF-32002 & NBF-32102 & NBF-32202 & NBF-32302 & NBF-32402
REVISION
DATE
8/31/2010
MATERIAL
ABS
CLEAR PC
ABS / PC BLEND
PBT / PC BLEND
FINISH:
BODY_______________________ LIGHT GRAY
COVER______________________ LIGHT GRAY OR CLEAR
LATCHES & HINGES___________ PLASTIC
WALL MOUNTING BRACKETS__ STAINLESS STEEL
& HARDWARE
5.118in
130.00mm
C
BODY
B
1.969in
50.00mm
3.169in
80.50mm
INSIDE WIDTH MAX.
3.107in
78.92mm
INSIDE WIDTH MIN.
COVER
ASSEMBLY
.807in
20.50mm
3.917in
99.50mm
3.917in
99.50mm
A
A
.689in
17.50mm
.394in
10.00mm
TYP.
.591in
15.00mm
4.370in
111.00mm
INSIDE LENGTH MAX.
B
.126in
3.20mm
FOR M4 x 10mm LG.
SELF-TAPPING SCREWS
2 PLCS.
( ABS VERSIONS ONLY )
M4 THREADED INSERTS
ON ALL OTHER VERSIONS
USE M4 x 8mm LG.
MACHINE SCREWS.
2 PLCS.
SECTION B-B
C
SECTION C-C
1.584in
40.24mm
SECTION A-A
NOTES:
1) UNIT COMES COMPLETE WITH (4) WALL MOUNTING
BRACKETS & (4) M4 x 10mm LG. SELF-TAPPING SCREWS.
(NOT SHOWN)
4.308in
109.42mm
INSIDE LENGTH MIN.
2.273in
57.74mm
2.776in
70.50mm
2.598in
66.00mm
3.780in
96.00mm
.126in
3.20mm
FOR M4 x 10mm LG.
SELF-TAPPING SCREWS
4 PLCS.
2)
BOXES DESIGNED TO MEET FOLLOWING STANDARDS:
NEMA 1,2,4,4X AND IEC529-IP65 REQUIREMENTS.
5.286in
134.25mm
TOLERANCES:
ALL DIMENSIONS HAVE
0.039in. [ 1mm] TOLERANCE
UNLESS OTHERWISE SPECIFIED.
PART NO.
MATERIAL
BODY
ABS
COVER
ABS
ABS / PC
CLEAR
PC
PBT / PC
CLEAR
PC
USE
INDOOR
INDOOR
INDOOR
OUTDOOR
OUTDOOR
NBF-32002
NBF-32102
ABS / PC
NBF-32202
ABS / PC
NBF-32302
NBF-32402
PBT / PC
PBT / PC
