188.00
[7.402] 178.00
[7.008]
216.64
[8.529]
A
61.51
[2.422]
INSIDE
HEIGHT
178.00
[7.008]
166.42
[6.552]
B
B
188.00
[7.402]
167.67
[6.601]
INSIDE
WIDTH
A
TOP VIEW
6.00
[.236]
2.50
[.098]
68.50
[2.697]
SECTION A-A
END VIEW
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc.)
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
(Part number and text placement/orientation on our products are subject to change,
we do not recommend using them as a locating reference for modification purposes)
0.15
0.11
8X 6-32 UNC
172.02
[6.772]
2.00
[.079]
4.00
[.157]
63.00
[2.480]
9.53
[.375]
183.00
[7.205]
3.96
[.156]
172.03
[6.773]
154.94
[6.100]
NOTE
Purchased assembly includes box, lid and 8 cover screws.
Box and lid are made from Diecast Aluminum Alloy.
Silicone Gasket supplied with liquid resistant enclosure.
Bottom Flange is Welded.
167.43
[6.592]
INSIDE LENGTH
183.00
[7.205]
205.36
[8.085]
Recommended Torque: 50-55 cN.m [71-78 ozf.in]
Recommended Torque with Gasket : 25-30 cN.m [36-43 ozf.in]
SECTION B-B
SIDE VIEW
182.57
[7.188]
78.56
[3.093]
4.49
[.177]
PART NUMBERS
1590FF Enclosure
1590FF
Natural Finish Enclosure
1590FFBK
Black Textured Enclosure
1590FF Liquid Resistant Enclosure (Silicone Gasket)
1590WFF
Natural Finish Enclosure
1590WFFBK
Black Textured Enclosure
ACCESSORIES
171.07
[6.735]
INSIDE BOX
2.00
[.079]
Liquid Resistant Cover Screws
Stainless Steel Cover Screws (Pkg 100)
[6-32 x 1/2" With O-Ring]
Black Stainless Steel Cover Screws (Pkg 100)
[6-32 x 1/2" With O-Ring]
1590WMS100
1590WMS100BK
78.56
[3.093]
180.80
[7.118]
171.07
[6.735]
Standard Cover Screws
Plated Cover Screw s (Pkg 100)
[6-32 x 1/2"]
Black Cover Screws (Pkg 100)
[6-32 x 1/2"]
1590MS100
1590MS100BK
8X
4.00
[.157]
4.00
[.157]
Dimensions:
mm
[inches]
INSIDE LID
1590FF
