Type 1 Unpainted Galvanized Steel Junction Box (CSG Series) - Hammond Mfg.
Quality Products. Service Excellence.
Type 1 Unpainted Galvanized Steel Junction Box
CSG Series
Screw Cover and without Knockouts
Application
Designed for general purpose indoor commercial use as a junction, pull or switch box.
Standards
UL-50 Type 1
CSA Type 1
Complies with
NEMA Type 1
IEC 60529, IP20
Construction
Formed and spot welded from 16 or 14 gauge G90 galvanized steel depending on size.
Flat steel covers fastened with plated steel screws.
Keyhole slots permit cover to be lifted off without removing screws entirely.
Through holes in back for wall mounting.
Grounding location embossed in body.
Finish
Enclosure and cover are unpainted galvanized steel.
Overall Dimensions
Part No.
CSG664
CSG884
CSG10104
A
6.00
8.00
10.00
B
6.00
8.00
10.00
C
4.00
4.00
4.00
Mtg. Centers
D
3.00
5.00
7.00
E
5.00
7.00
9.00
F
1.50
1.50
1.50
G
0.50
0.50
0.50
H
0.28
0.28
0.28
https://www.hammfg.com/electrical/products/commercial/csg
1/2
11/20/2017
Type 1 Unpainted Galvanized Steel Junction Box (CSG Series) - Hammond Mfg.
Overall Dimensions
Part No.
CSG12124
CSG666
CSG886
CSG10106
CSG12106
CSG12126
CSG18126
CSG18186
CSG24246
CSG12128
CSG18188
CSG24248
CSG363612
CSG484812
CSG484816
A
12.00
6.00
8.00
10.00
12.00
12.00
18.00
18.00
24.00
12.00
18.00
24.00
36.00
48.00
48.00
B
12.00
6.00
8.00
10.00
10.00
12.00
12.00
18.00
24.00
12.00
18.00
24.00
36.00
48.00
48.00
C
4.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
8.00
8.00
8.00
12.00
12.00
16.00
Mtg. Centers
D
9.00
3.00
5.00
7.00
9.00
9.00
15.00
15.00
21.00
9.00
15.00
21.00
33.00
45.00
45.00
E
11.00
5.00
7.00
9.00
9.00
11.00
11.00
17.00
22.50
11.00
17.00
22.50
34.50
46.50
46.50
F
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
G
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.75
0.50
0.50
0.75
0.75
0.75
0.75
H
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.44
0.28
0.28
0.44
0.44
0.44
0.44
Data subject to change without notice
© 2017. Hammond Manufacturing Ltd. All rights reserved.
