Type 1 Mild Steel Junction Box (CS Series) - Hammond Mfg.
Quality Products. Service Excellence.
Type 1 Mild Steel Junction Box
CS Series
Screw Cover and without Knockouts
Application
Designed for general purpose indoor commercial use as a junction, pull or switch box.
Standards
UL-50 Type 1
CSA Type 1
Complies with
NEMA Type 1
IEC 60529, IP20
Construction
Formed and spot welded from 16, 14 or 12 gauge steel depending on size.
Flat steel covers fastened with plated steel screws.
Keyhole slots permit cover to be lifted off without removing screws entirely.
Through holes in back for wall mounting.
Grounding location embossed in body.
Finish
Enclosure and cover are finished in ANSI 61 gray powder coating.
Overall Dimensions
Part No.
CS443
CS663
CS863
CS16143
A
4.00
6.00
8.00
16.00
B
4.00
6.00
6.00
14.00
C
3.00
3.00
3.00
3.00
Mtg. Centers
D
2.00
3.00
5.00
13.00
E
3.00
5.00
5.00
13.00
F
0.88
1.50
1.50
1.50
G
0.50
0.50
0.50
0.50
H
0.28
0.28
0.28
0.28
https://www.hammfg.com/electrical/products/commercial/cs
1/2
11/18/2017
Type 1 Mild Steel Junction Box (CS Series) - Hammond Mfg.
Overall Dimensions
Part No.
CS18143
CS20143
CS444
CS644
CS664
CS864
CS884
CS1084
CS10104
CS1284
CS12104
CS12124
CS16124
CS18124
CS18184
CS24244
CS666
CS886
CS1086
CS10106
CS12106
CS12126
CS16126
CS16166
CS18126
CS18186
CS24186
CS24246
CS30246
CS36246
CS36366
CS12128
CS16168
CS18188
CS24248
CS36248
CS202010
CS242410
CS302010
CS362410
CS363612
A
18.00
20.00
4.00
6.00
6.00
8.00
8.00
10.00
10.00
12.00
12.00
12.00
16.00
18.00
18.00
24.00
6.00
8.00
10.00
10.00
12.00
12.00
16.00
16.00
18.00
18.00
24.00
24.00
30.00
36.00
36.00
12.00
16.00
18.00
24.00
36.00
20.00
24.00
30.00
36.00
36.00
B
14.00
14.00
4.00
4.00
6.00
6.00
8.00
8.00
10.00
8.00
10.00
12.00
12.00
12.00
18.00
24.00
6.00
8.00
8.00
10.00
10.00
12.00
12.00
16.00
12.00
18.00
18.00
24.00
24.00
24.00
36.00
12.00
16.00
18.00
24.00
24.00
20.00
24.00
20.00
24.00
36.00
C
3.00
3.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
4.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
6.00
8.00
8.00
8.00
8.00
8.00
10.00
10.00
10.00
10.00
12.00
Mtg. Centers
D
15.00
17.00
2.00
3.00
3.00
5.00
5.00
7.00
7.00
9.00
9.00
9.00
13.00
15.00
15.00
21.00
3.00
5.00
7.00
7.00
9.00
9.00
13.00
13.00
15.00
15.00
21.00
21.00
27.00
33.00
33.00
9.00
13.00
15.00
21.00
33.00
17.00
21.00
27.00
33.00
33.00
E
13.00
13.00
3.00
3.00
5.00
5.00
7.00
7.00
9.00
7.00
9.00
11.00
11.00
11.00
17.00
23.00
5.00
7.00
7.00
9.00
9.00
11.00
11.00
15.00
11.00
17.00
17.00
22.50
22.50
22.50
34.50
11.00
15.00
17.00
22.50
22.50
19.00
22.50
18.50
22.50
34.50
F
1.50
1.50
0.88
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
G
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.75
0.75
0.75
0.75
0.50
0.50
0.50
0.75
0.75
0.75
0.50
0.75
0.75
0.75
H
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.44
0.44
0.44
0.44
0.28
0.28
0.28
0.44
0.44
0.44
0.28
0.44
0.44
0.44
Data subject to change without notice
© 2017. Hammond Manufacturing Ltd. All rights reserved.
