Top View of Assembly
130.00
[5.118]
SECTION A-A
End View of Assembly
A
47.00
[1.850]
52.25
[2.057]
65.00
[2.559]
1.00
[.039]
B
B
B
B
A
79.50
[3.130]
25.50
[1.004]
SECTION B-B
Side View of Assembly
Top View Looking Inside Box
31.75
[1.250]
19.25
[.758]
5.30
[.209]
2.50
[.098]
8.90
[.350]
40.00
[1.575]
2.50
[.098]
117.25
[4.616]
28.05
[1.104]
50.00
[1.969]
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc. )
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
NOTE
Lid
Divider
50.00
[1.969]
A
33.01
[1.300]
4.75
[.187]
59.00
[2.323]
32.96
[1.298]
18.00
[.709]
38.00
[1.496]
Purchased assembly includes box, lid and 4 cover screws. Flame retardant ABS
carries UL flammability rating of 94 V-0. Various Battery holder kits available.
Maximum P.C. Board Size
70.50
[2.776]
50.00
[1.969]
40.00
[1.575]
53.00
[2.087]
n
3.40
PART NUMBERS
1599B Fire Retardant ABS with Battery Door
Black FR-ABS
1599BBKBAT
Grey FR-ABS
1599BGYBAT
1599B General Purpose ABS with Battery Door
Black GP-ABS
1599BSBKBAT
1599BSGYBAT
Grey GP-ABS
ACCESSORIES
Cover Screws for FR-ABS (Pkg 100)
1594MS100
[M3 - 0.5 x 20mm Nickel Plated Machine Screws]
Cover Screws for GP-ABS (Pkg 100)
1599BTS100
[#4 x 3/4" Stainless Steel Self Tapping Screws]
1593ATS50
P.C Board Mounting Screws (Pkg of 50 or 100)
1593ATS100
[#4 x 1/4" Self Tapping Screws]
[.134]
A
40.00
[1.575]
51.15
[2.014]
R3.50
[.138]
R4.50
[.177]
89.25
[3.514]
1599BBAT
