P180804(x) CONFIGURATIONS
-S
-U
-UB
P180804 COVER
1
P180804 COVER w/USB OPENING
1
P180804 COVER w/USB & BUTTON HOLE
1
P180804 BASE
1
P180804 BASE w/USB
1
1
P180804 BUTTON
P210603 CAP
-UBC -UBB
-B
-C
R E V I S I O N
REV.
1
DRAWN BY
M BOYER
M BOYER
M BOYER
M BOYER
M BOYER
M BOYER
M BOYER
M BOYER
R CRUZ
3909
0710
0810
1810
2711
3611
8413
4514
ECO No
DESCRIPTION
PRELIMINARY RELEASE
REVISIONS 2-11 ARCHIVED ON REV 12.1
REDUCE ALIGNMENT POST HEIGHT BY .025"
UPDATE FORMAT
INCLUDE GATE DETAIL INFORMATION
UPDATE CONFIGURATION TREE - INCLUDE BUTTON
UPDATE ASSY POST DIA TO "PRESS FIT"
ADD NOTE RE ASSEMBLY POSTS
UPDATE TO AS BUILT - DIR 0274
ADD PCB RIB NOTE FOR COVER
DATE
04-May-05
28-Oct-09
19-Mar-10
08-Apr-10
14-Jun-10
25-Jul-11
21-Oct-11
07-Jan-14
17-Oct-14
APPROVED
D.C.
D.C.
D.C.
D.C.
D.C.
D.C.
D.C.
D.C.
1
1
1
12
1
12.1
12.2
12.3
12.4
12.5
13.0
13.1
'UB' SERIES ONLY
NOTES:
UNLESS OTHERWISE SPECIFIED
1. CORNERS DRAWN SHARP TO BE R.005 MAXIMUM.
NOTE 12
USB OPENING
'U' & 'UB'
SERIES ONLY
2. EXTERIOR SURFACE TEXTURE TO BE LIGHT EDM FINISH (EQUIVALENT TO MT-11010.)
3. INTERIOR SURFACE TEXTURE TO BE:
NONE
4. ALL INSIDE RADII .010R. UNLESS OTHERWISE SPECIFIED.
5. ALL EXTERNAL DIMENSIONS AFFECTED BY THE DRAFT APPLY AT THE LARGE END OF
THE FEATURE, AND ALL INTERNAL FEATURES AFFECTED BY THE DRAFT APPLY AT
THE SMALL END OF THE FEATURE UNLESS OTHERWISE SPECIFIED.
6. 1 DEGREE DRAFT IN THE DIRECTION OF PULL IS PERMISSIBLE UNLESS
OTHERWISED SPECIFIED.
7. THIS ENCLOSURE IS A PRESS FIT ASSEMBLY. FOR PERMANENT CLOSURE: A DROP
ADHESIVE OR ULTRASONIC WELDING IS REQUIRED.
8. MATERIAL / COLOR:
ABS PLASTIC IS STANDARD IN BLACK OR WHITE.
CUSTOM MATERIALS AND COLORS ARE AVAILABLE UPON REQUEST FOR QUOTE.
9. PCB SIZES ARE RECOMMENDATIONS ONLY. FINAL SIZES AND VERIFICATION
OF ITS FIT ARE THE SOLE RESPONSIBILITY OF EACH CUSTOMER.
10. STANDARD OR CUSTOM LABEL RECESSES ARE AVAILABLE FOR QUOTE.
11. "STANDARD" VERSION ENCLOSURE COVER NOT AVAILABLE WITH RIBS.
SHEET 4 FOR DETAILS.
SEE
USB CAP
NOT SHOWN
NOTE 12
SCALE 2.000
USB OPENING
U & UB
SERIES ONLY
12. THE GATE REMNANT FOR THIS ENCLOSURE IS LOCATED IN THIS POSITION
TO MINIMIZE ANY COSMETIC IMPACT. IT IS HOWEVER VISIBLE AND VARIES
IN SIZE / SHAPE. IT IS EASILY REMOVED WITH CLIPPERS. IF YOU
WOULD LIKE NEW AGE TO CLIP THIS FOR YOU, PLEASE ASK YOUR SALES
REPRESENTIVE FOR A FREE QUOTE.
13. ASSEMBLY POST DIMENSIONS WILL VARY DEPENDING ON THE "PRESS FIT"
OF THE ENCLOSURE.
THIRD ANGLE PROJECTION
TOLERANCES: UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN U.S. INCHES.
5
4
3
2
1
180804 PCB - REFERENCE
180804UB COVER - STANDARD
180804UB BASE - STANDARD
210603 CAP
180804 BUTTON
.028" THICK
ABS
ABS
SOLD SEPERATE
SOLD SEPERATE
CUSTOMER SUPPLIED
BLACK or WHITE
BLACK or WHITE
--
--
1
1
1
1
1
DO NOT SCALE DRAWING
NOTICE: THE INFORMATION AND DATA
CONTAINED HEREIN IS CONSIDERED
PROPRIETARY TO ALLTEC INTEGRATED
MFG INC & SHALL REMAIN THE EXCLUSIVE
PROPERTY OF ALLTEC INTEGRATED MFG INC
THE HOLDER WILL ASSUME CUSTODY AND
CONTROL THAT THIS DOCUMENT WILL
NOT BE COPIED, REPRODUCED, OR
DISCLOSED WITHOUT THE EXPRESS WRITTEN
CONSENT OF ALLTEC INTEGRATED MFG INC
POSSESSION OF THIS DOCUMENT DOES
NOT CONSTITUTE A GRANT TO
MANUFACTURE ANY ITEMS.
© 2014
NEW AGE ENCLOSURES
Customer's Part No:
APPROVAL
CHECK
ENG.
SCALE
DRAWN BY
BY
DATE
X.XX = .015 X.XXXX = .001
X.XXX = .010
X.X° = 1°
180804
4330 Santa Fe Road
ph. (805) 595-1310
www.newageenclosures.com
San Luis Obispo, CA. 93401
fax (805) 595-1024
ITEM
DESCRIPTION
MATERIAL
COLOR
QTY.
AS NOTED
SIZE
STANDARD - USB DRIVE
PXX-180804XX-XXX
A
DRAWING NAME
SHEET
BILL OF MATERIALS
M BOYER
04-May-05
180804_R13_1
1 OF 8
13.1
REV.DOC
