125.40
[4.94]
A
113.00
[4.45]
50.80
[2.00]
(INSIDE
DEPTH)
B
80.40
[3.17]
B
68.00
[2.68]
70.64
[2.78]
(INSIDE
WIDTH)
A
TOP VIEW
58.80
[2.31]
SECTION A-A
END VIEW
1.50
[.06]
113.39
[4.46]
15.60
[.61]
97.20
[3.83]
4.61
[.18]
3.81
[.15]
(AVERAGE
WALL
THICKNESS)
6.00
[.24]
44.70
[1.76]
68.00
[2.68]
98.22
[3.87]
44.20
[1.74]
68.39
[2.69]
C
UL
O
®
US LISTED
FILE #E65324
NEMA 4, 4X
116.04
[4.57]
113.00
[4.45]
3.60
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc.)
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
(Part number and text placement/orientation on our products are subject to change,
we do not recommend using them as a locating reference for modification purposes)
(INSIDE LENGTH
)
NOTE
Purchased assembly includes box, lid, silicone gasket,
4 cover screws and 2 ground screws with washers.
Box and lid are made from Diecast Aluminum Alloy.
Recommended cover screw Torque 5-7.5 lbf.in ( 50 -75 cN.m)
SECTION B-B
SIDE VIEW
[.14]
INSIDE LID
117.25
[4.62]
101.05
[3.98]
C
ACCEPTS
M4 MACHINE
GROUND SCREW
ACCEPTS M4 - 0.7
MACHINE SCREW
1590Z120
1590Z120 Enclosure
Basic Enclosure
Black Enclosure
Grey Enclosure - RAL7001 Gloss
6.94
[.27]
113.00
[4.45]
24.00
[.94]
15.00
[.59]
12.70
[.50]
DRAWINGS
AVALIBLE
FOR STEEL
INNER PANEL
106.00
[4.17]
13.40
[.53]
1590Z120
1590Z120BK
1590Z120GY
1590Z120PL
1590Z120G
52.00
[2.05]
72.25
[2.84]
48.05
[1.89]
ACCESSORIES
Steel Inner Panel
Pre-Formed Silicone Gasket
Copper Ground Hardware (2 Pack)
[M4 - 0.7 X 6mm / M4 Washer]
SCGM4
4.06
[.16]
SECTION C-C
MOUNTING HOLE
C
INSIDE BOX
®
Dimensions:
mm
[inches]
1590Z120
www.hammondmfg.com
