15W DC-DC Regulated Dual Output Converter
DKE15
series
SPECIFICATION
ORDER NO.
DC VOLTAGE
CURRENT RANGE
RATED POWER
OUTPUT
¡½
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡E
¡Ó
5V
¡Ó
150 ~
¡Ó
1500mA
15W
Features :
2:1 wide input range
4:1 wide input range(optionl)
1000VDC I/O isolation
3000VDC I/O isolation(option)
Built-in EMI filter
Protections: Short circuit / Overload
Cooling by free air convection
Six-sided shield metal case
100% burn-in test
Low cost / High reliability
Approvals: FCC / CE
2 years warranty
DKE15A- DKE15B- DKE15C- DKE15A- DKE15B- DKE15C- DKE15A- DKE15B- DKE15C- DKE15A- DKE15B- DKE15C-
05
05
05
12
12
12
15
15
15
24
24
24
¡Ó
12V
¡Ó
62.5 ~
¡Ó
625mA
60mVp-p
¡Ó
15V
¡Ó
50 ~
¡Ó
500mA
60mVp-p
¡Ó
24V
¡Ó
31.3 ~
¡Ó
313mA
80mVp-p
RIPPLE & NOISE (max.)
Note.2
50mVp-p
LINE REGULATION
Note.3
0.3%
LOAD REGULATION
VOLTAGE ACCURACY
VOLTAGE RANGE
EFFICIENCY (Typ.)
¡Ó
Note.4
¡Ó
0.5%
¡Ó
2.0%
SWITCHING FREQUENCY
150KHz min.
A: 9 ~ 18VDC B: 18~36VDC
83%
81%
79%
Full load
No load
A: 40mA
B: 20mA
C: 36~72VDC
82%
83%
C: 400mA
C: 10mA
82%
82%
83%
82%
82%
84%
85%
INPUT
DC CURRENT
FILTER
PROTECTION
OVER CURRENT
A: 1700mA B: 800mA
Pi network
Fuse recommended
160% ~ 250% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
All output equipped with short circuit
Protection type : Hiccup mode, recovers automatically after fault condition is removed
PROTECTION
(Note. 5)
SHORT CIRCUIT
WORKING TEMP.
WORKING HUMIDITY
-25~+71 (Refer to output load derating curve)
20% ~ 90% RH non-condensing
ENVIRONMENT STORAGE TEMP., HUMIDITY
-25 ~ +105 , 10 ~ 95% RH
0.03% / ( 0 ~ 50 )
TEMP. COEFFICIENT
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
VIBRATION
¡Ó
¢J
¢J
¢J
¢J
WITHSTAND VOLTAGE
SAFETY & ISOLATION RESISTANCE
EMC EMISSION
EMC
EMC IMMUNITY
OTHERS
MTBF
DIMENSION
WEIGHT
I/P-O/P:1KVDC
I/P-O/P: 100M Ohms / 500VDC / 25
¢J
/ 70% RH
Compliance to EN55022 Class B, FCC part 15 Class B
Compliance to EN61000-4-2,3,4,5,6,8, light industry level, criteria A
300Khrs min. MIL-HDBK-217F (25 )
50.8*50.8*11.0mm or 2"*2"*0.43" inch (L*W*H)
¢J
65g
Mechanical Specification
Unit: mm (inch)
50.8 (2.00)
20.30 (.800) 15.2 (.598)
10.20 10.20
(.402) (.402) 15.2 (.598)
Pin Configuration
Derating Curve
5.8 (0.23)
11 (0.43)
Pin No.
1
2
3
4
5
Output
+ Vi n
- Vi n
+ Vo u t
COM
- Vo u t
100
LOAD (%)
22.8 (.898)
80
50.8 (.200)
3
1
2
4
5
BOTTOM VIEW
5.10 (.200)
1.0 + 0.2/-0.1
£r
-25
0
25
50 60 71
Ta (
NOTE
1.All parameters are specified at normal input, rated load, 25 70% RH ambient.
2.Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1uf & 47uf capacitor.
3.Line regulation is measured from low line to high line at rated load.
4.Load regulation is measured from 10% to 100% rated load.
5.Please prevent the converter from operating in overload or short circuit condition for more than 30 seconds.
¢J
¢J
)
100
File Name:DKE15-SPEC 2012-07-18
