DC and Signal Connector: Tyco Part # 1-6450132-2, or FCI PowerBlade # 51732-021
P1
P2
P3
P4
P5
P6
P7
P8
x1
AC_OK
SPARE
V
OUT
V
OUT
V
RTN
V
RTN
V
RTN
V
RTN
V
OUT
V
OUT
I_SHARE
SENSE +
I
2
C ADR0
SENSE -
I
2
C ADR1
I
2
C DATA
I
2
C ADR2
I
2
C
CLOCK
PS_KILL
SPARE
PS_
PRESENT
PS_ON
B
A
x2
P_GOOD
SPARE
x3
V_
SB
RETURN
V_
SB
RETURN
x4
V_
SB
RETURN
V_
SB
RETURN
x5
V_
SB
+OUT
V_
SB
+OUT
x6
V_
SB
+OUT
V_
SB
+OUT
D
C
mate-last pins
Pin Assignment
P1, P2, P7, P8
P3, P4, P5, P6
A1
A2
C5, C6, D5, D6
C3, C4, D3, D4
B1
D1
D2
B5
B6
A6
A3
A4
B2
B3
B4
Signal Name
V
OUT
V
RTN
Sense +
Sense -
V_
SB
V_
SB
Return
I_Share
AC_OK
P_Good
PS_Kill
PS_Present
PS_On
I
2
C Data
I
2
C Clock
I
2
C Adr0
I
2
C Adr1
I
2
C Adr2
Description
Main output voltage
Main output voltage, return
V
OUT
remote sense, positive node input, connected to the
+ve load point
V
OUT
remote sense, negative node input, connected to the
-ve load point
Standby voltage output
Standby voltage, return, tied internally to Output Return
Active load sharing bus
Input AC Voltage “OK” signal output (Internal pull up is
10kΩ to Vsb)
Power good signal output (Internal pull up is 10kΩ to Vsb)
Floating pin will turn off P/S (shorter pin, last-make and
first-break contact for hot plugging). This signal overrides
PS-On in disabling the Main Output
Internally tied to Vsb return
Internal 1K ohm pull-up to Vsb, (accepts open collector/
drain drive), This signal to be pulled low to turn-on power
supply
I
2
C serial data bus
I
2
C serial clock bus
Address input 0, internal pull-up to Vsb
Address input 1, internal pull-up to Vsb
Address input 2, internal pull-up to Vsb
High Level
Low Level
I Max
0 – 8V
>2.4V (active, OK)
<0.4V
>2.4V (active, Good)
<0.4V
>2.1V (open, or Vsb)
<0.7V (active, PS:On)
0V
>2.1V (open, or Vsb)
<0.7V (active, PS:On)
Vsb
Vsb
>2.1V, < Vsb
<0.8V
>2.1V, <Vsb
<0.8V
>2.1V, <Vsb
<0.8V
-4 mA / +5 mA
+4 mA
-2 mA
+4 mA
-2 mA
N/A
-4 mA
-1 mA
±1 mA
±1 mA
±1 mA
D1U4 MATING CONNECTORS
12V D1U4 mating connector
Press Fit
Straight
Murata-PS
FCI
Tyco
N/A
51742-10802400CALF
TBD
Solder
1
Right Angle
Straight
N/A
51742-10802400AALF
TBD
Right Angle
36-0430032-0
51762-10802400ABLF
TBD
N/A
51762-10802400CBLF
TBD
1 Solder connector recommended for board thickness of <0.090
www.murata-ps.com/support
CPS_D1U4-W-1600-12-Hx.B02
Page 4 of 6
D1U4-W-1600-12-Hx Series
AC/DC Front End Power Supply
WIRING DIAGRAM FOR OUTPUT
Dotted lines show optional remote sense connections.
Optional remote sense lines can be attached to a load that is a distance
away from the power supply to improve regulation at the load.
Sense + (Main Output Remote Sense)
A1
P1, P2, P7, P8
VOUT
Sense + (Main Output Remote Sense)
VOUT
A1
P1, P2, P7, P8
12V load
P3, P4, P5, P6
A2
B1
VRTN
Sense -
I_Share
VRTN
Sense -
I_Share
P3, P4, P5, P6
A2
B1
D1U4
D1U4
C5, C6, D5, D6
A6
V_SB
PS_On
Close switch (or FET, BJT, or wire)
to turn on +12V OUT
+5V logic circuitry
V_SB
PS_On
C5, C6, D5, D6
A6
C3, C4, D3, D4
V_SB Return
V_SB Return
C3, C4, D3, D4
B5
PS_Kill
PS_Kill
B5
CURRENT SHARING NOTES
12V Output: Current sharing is achieved using the active current share method. (See wiring diagram for connection details.)
The total combined load must be below 1600W at startup. Current sharing can be achieved with or without remote sense connected to the common load.
V_SB outputs can be tied together for redundancy but total combined output power must not exceed 20W. The V_SB output has internal ORing MOSFET for
additional redundancy / internal short protection.
The current share pin B1 is a connection between the two units. It is input and/or output as the voltage on the line controls the current share. A power
supply will respond to a change in this voltage but a power supply can also change the voltage depending on the load drawn from it. On a single unit this
would read 8V at 100% load. For two units sharing load then this should read 4V for perfect current sharing.
Up to 6 units can be paralleled together. Please consult your Murata sales representative if operation with more than six units in parallel is needed.
