TR100
S
E
R
I
E
S
Specifications
INPUT SPECIFICATIONS:
Voltage ......................................................................................90 ~ 264Vac
Frequency .....................................................................................47 to 63Hz
Inrush Current...............................................................100A max. @240Vac
Conducted EMI.............................................................. CISPR/FCC Class B
Isolation ............................................................ lnput to output =4,242VDC
Leakage Current.........................................................................3.5mA max
100%
80%
60%
TR100 Series Derating Curve
TR100 derating curve
0
20LFM(Natural Convection)
40%
20%
0%
0
10
20
30
40
50
60
Ambient Temperature(˚C)
100W SWITCHING
ADAPTER WITH PFC
PS
E
6
OUTPUT SPECIFICATIONS:
Holdup Time ..................................................................20mS typ. @115Vac
Short Circuit Protection ............................................................. Continuous
Over Voltage Protection .........................................................................Yes
NOTE:
1. Voltage accuracy is set at 60% full load.
2. Add a 0.1µF ceramic capacitor and a 10µF E.L. capacitor to output for Ripple &
Noise measurement @20MHz BW.
3. Line regulation is measured from 100Vac to 240Vac, full load.
4. Load regulation is measured from 60% to 100% full load and from 60% to 20% full load
(60% +/- 40% full load)
5. Cable
100%
Length Iimit for TR100A120/150:1200mm(max.)
90%
Cable Length Iimit for TR100A180/190/240/480:1800mm(max.)
80%
(For Customer Design)
70%
6. "Various TR Series adapters are PSE certified. PSE certification alone is not suffcient for
importation into Japan. A valid PSE mark must contain the name of the importer as
60%
shown in the example below. If PSE mark is required, the name of the registered
50%
importer must be supplied to Cincon on order placement. Product Iabels will not
40%
contain PSE mark if importer name is not supplied. Consult factory or local represen
30%
tative for details"
PS
IMPORTER NAME
20%
JET
E
INPUT
OUTPUT
AU100-240V, 0.5A
33-44VA, 50-60Hz
DC 5V, 2A
ENVIRONMENTAL CHARACTERISTICS:
Operating Temperature .................................................................
0 ~ 40˚C
Storage Temperature ...................................................................-20
~ 85˚C
Cooling..........................................................................Natural Convection
Features
• Universal Input Range 90-264VAC
• Meets EN55022 Class B and
CISPR/FCC Class B, Conducted
Ordering information
TR100AXXX - XX
E
XX
MECHANICAL CHARACTERISTICS:
Dimensions .........150.00 x 70.00 x 35.00mm(5.906 x 2.756 x 1.378 Inches)
Weight .............................................................................600g (1.36Pounds)
Output Load(%)
• Continuous Short Circuit Protection
• Over Voltage Protection
10%
Natural Convection
Mechanical Specification
All Dimensions In Inches(mm)
Tolerance
Inches: x.xxx= ±0.02
Millimeters: x.xx= ±0.5
0%
0
10
20
30
40
50
60
70
80
90
100
Model No.
DC Plug Type
* Please see Page235 for more detailed descriptions
DC Cable Length and Type
11 : 720mm with Ferrite Core
12 : 1200mm with Ferrite Core
13 : 1800mm with Ferrite Core
21 : 720mm with two Ferrite Core
22 : 1200mm with two Ferrite Core
23 : 1800mm with two Ferrite Core
* 16AWG / UL2464
Ambient Temperature(˚C)
MODEL
OUTPUT MAX.
VOLTAGE LOAD
12V
15V
18V
19V
24V
28V
29V
30V
36V
48V
8.33 A
6.67 A
5.56 A
5.21 A
4.17 A
3.54 A
3.41 A
3.30 A
2.78 A
2.08 A
MIN. RIPPLE & VOLTAGE
LINE
LOAD
LOAD NOISE ACCURACY REGULATION REGULATION
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
± 2%
± 2%
± 2%
± 2%
± 2%
± 2%
± 2%
± 2%
± 2%
±2%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 1%
± 4%
± 4%
± 2%
± 2%
± 2%
± 2%
± 2%
± 2%
± 2%
± 2%
SWITCHING
FREQUENCY
67KHz Typ.
67KHz Typ.
67KHz Typ.
67KHz Typ.
67KHz Typ.
67KHz Typ.
67KHz Typ.
67KHz Typ.
67kHz Typ.
67KHz Typ.
%EFF.
85% min.
85% min.
85% min.
85% min.
85% min.
85% min.
85% min.
85% min.
85% min.
85% min.
TR100A120
TR100A150
TR100A180
TR100A190
TR100A240
TR100A280
TR100A290
TR100A300
TR100A360
TR100A480
Distributed by:
Power Sources Unlimited, Inc., Wrentham, MA
221
Tel: 508-384-1419 | E-mail: sales@psui.com | Website: www.psui.com
Typical at 25˚C, nominal line and 75% load, unless otherwise Specified
222
T R 1 0 0
