INPUT SPECIFICATIONS:
Input Voltage Range......................12V.................................................9-18V
24V...............................................18-36V
48V...............................................36-72V
Input Filter..............................................................................................Pi Type
Output Load(%)
120%
-25
71
100%
80%
60%
40%
20%
0%
-25
0
25
50
75
100
S
E
R
I
E
S
OUTPUT SPECIFICATIONS:
Voltage Accuracy
Single Output................................................................±1.0% max.
Dual + Output...............................................................±1.0% max.
Dual - Output................................................................±3.0% max.
Voltage Balance Dual Output at Full Load...............................±1.0% max.
Transient Response
Single 25% Step Load Change.....................................................<500µ sec.
Dual FL-1/2L ±1% Error Band..........................................................<500µ sec.
Ripple & Noise 20MHz BW...................................................10mV RMS. max.
75mV p-p max.
Temperature Coefficient...............................................................±0.02%/˚C
Short Circuit Protection.........................................Indefinite & Current Limit
Line Regulation
1
Single/Dual Output........................................±0.2% max.
Load Regulation
2
Single/Dual Output......................................±1.0% max.
15 WATT
EN55022 CLASS B
DC-DC CONVERTERS
Natural
Convection
100
Ambient Temperature(˚C)
NOTE:
1. Measured From High Line to Low Line
2. Measured From Full Load to 1/4 Full Load
3. Determine the Correct Fuse Size by Calculating the Maximum DC Current Drain at
Low Line Input, Maximum Load and Then Adding 20 to 25% to Get Desired Fuse Size.
4. Alternative Pin Configuration Suffix "S"
5. Maximum case temperature under any operating condition should not exceed 100˚C.
Features
•
•
•
•
•
15W Isolated Output
2"x 2" Six-Sided Shield Metal Case
Regulated Outputs
Efficiency to 82%
Fixed 200KHz Switching Frequency
INPUT
VOLTAGE
OUTPUT
VOLTAGE
5 VDC
12 VDC
15 VDC
9-18 VDC
±12 VDC
±15 VDC
±5 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
18-36 VDC
±12 VDC
±15 VDC
±5 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
36-72 VDC
±12 VDC
±15 VDC
±5 VDC
3.3 VDC
OUTPUT
CURRENT
3000 mA
1250 mA
1000 mA
±625 mA
±500 mA
±1500 mA
3000 mA
3000 mA
1250 mA
1000 mA
±625 mA
±500 mA
±1500 mA
3000 mA
3000 mA
1250 mA
1000 mA
±625 mA
±500 mA
±1500 mA
3000 mA
•
•
•
•
Meets EN55022 Class B, Conducted
Pi Input Filter
Continuous Short Circuit Protection
Alternative Pin Configuration
GENERAL SPECIFICATIONS:
Efficiency.......................................................................................... See Table
Isolation Voltage........................................................................500 VDC min.
Isolation Resistance............................................................................10
9
ohms
Switching Frequency...................................................................200KHz, typ.
Operating Ambient Temperature Range .......................... -25˚C to +71˚C
De-rating, Above 71˚C ………………….. Linearly to Zero power at 100˚C
Case Temperature
5
…................…………..................................... 100˚C max
Cooling ……………………………………………….........Natural Convection
Storage Temperature Range..............................................-40˚C to + 100˚C
MODEL
NUMBER
EC3CB01
EC3CB02
EC3CB03
EC3CB04
EC3CB05
EC3CB06
EC3CB07
EC3CB11
EC3CB12
EC3CB13
EC3CB14
EC3CB15
EC3CB16
EC3CB17
EC3CB21
EC3CB22
EC3CB23
EC3CB24
EC3CB25
EC3CB26
EC3CB27
INPUT CURRENT
FULL LOAD
NO LOAD
30 mA
30 mA
30 mA
35 mA
35 mA
35 mA
30 mA
15 mA
20 mA
20 mA
25 mA
25 mA
25 mA
15 mA
10 mA
15 mA
15 mA
20 mA
20 mA
20 mA
20 mA
1660 mA
1625 mA
1625 mA
1620 mA
1620 mA
1620 mA
1178 mA
812 mA
772 mA
772 mA
780 mA
780 mA
780 mA
557 mA
390 mA
381 mA
381 mA
386 mA
386 mA
386 mA
271 mA
EMI/RFI.............................................Conductive EMI Meet EN55022 Class B
% EFF.
75
78
78
77
77
77
70
78
81
81
80
80
80
74
80
82
82
81
81
81
76
SIZE
Dimensions................................................................2.00 x 2.00 x 0.40 inches
(50.8 x 50.8 x 10.2mm)
Case Material....................................................Black Coated Copper With
Non-Conductive Base
Weight......................................................................................................... 57g
2" x 2"
CASE C
All Dimensions In Inches(mm)
Tolerance
Inches: .xx= ±.04, .xxx= ±.010
Millimeters: .x= ±1.0, .xx= ±0.25
STANDARD PIN CONFIGURATION
2.00
(50.8)
0.60
(15.2)
0.400 0.400
(10.16) (10.16)
0.60
(15.2)
0.040
DIA.
(1.02)
0.40
(10.2)
max.
ALTERNATIVE PIN CONFIGURATION SUFFIX "S"
2.00
(50.8)
1.700
(43.18)
+IN
0.22
(5.6)
min.
0.15
(3.8)
0.40
(10.2)
max.
0.15
(3.8)
2" x 2"
+OUT
NP*
-OUT
0.800
(20.32)
+OUT
0.850
(21.59)
2.00
(50.8)
COM
BOTTOM VIEW
1.650
(41.91)
2.00
(50.8)
BOTTOM
VIEW
COM/NP*
0.850
(21.59)
+IN -IN
0.60
(15.2)
-IN
-OUT
0.040
(1.02)
DIA.
2" x 2"
0.200
(5.08)
1.00
(25.4)
1.00
(25.4)
0.22
(5.6)
min.
NP* - NO PIN ON SINGLE OUTPUT MODLES
NOTE: 1. Nominal Input Voltage 12, 24 or 48 VDC
2. Alternative pin-out version. To order, suffix a "S" to the standard model number.
All Specifications Typical At Nominal Line, Full Load and 25˚C Unless Otherwise Noted.
E C 3 C B
EC3CB
Specifications
EC3CB Series Derating Curve
