Aluminum Electrolytic Capacitors
LSK Series
Features
Snap-in terminal type
105 , 5,000 hours assured
Suitable for medium to high voltage circuits
RoHS Compliance
LSK
Specifications
Items
Category Temperature Range
Capacitance Tolerance
Leakage Current (at 20
)
Where,
Performance
-25
~ +105
±20%
or 1.5 mA whichever is smaller (after 5 minutes)
V = rated DC working voltage in V
Rated Voltage
160
0.15
200
0.15
250
0.15
315
0.15
350
0.15
400
0.15
Sleeve & Marking Color: Black & White
(at 120Hz, 20
)
Tan (at 120Hz, 20
)
420
0.15
450
0.15
500
0.15
Low Temperature
Characteristics (at 120Hz)
Impedance ratio shall not exceed the values given in the table below.
Rated Voltage
160
200
250
315
350
400
420
Impedance
Z(-25 )/Z(+20 )
4
4
4
4
4
8
8
Ratio
450
8
500
8
Endurance
5,000 Hrs
Within ±25% of initial value
Less than 250% of specified value
Leakage Current
Within specified value
* The above specifications shall be satisfied when the capacitors are restored to 20
after the rated voltage applied with rated
ripple current for 5,000 hours at 105 .
1,000 Hrs
Within ±20% of initial value
Less than 150% of specified value
Leakage Current
Within specified value
* The above specifications shall be satisfied when the capacitors are restored to 20
after exposing them for 1,000 hours at 105
without voltage applied. The rated voltage shall be applied to the capacitors before the measurements (Refer to JIS C
5101-4 4.1).
Frequency (Hz)
Multiplier
3 % (During useful life)
-9
70 fit (70
×
10 /h)
50 / 60
0.8
100 / 120
1.0
300
1.1
1k
1.3
10k up
1.4
Test Time
Capacitance Change
Test Time
Capacitance Change
Shelf Life Test
Ripple Current and
Frequency Multipliers
Failure percentage
Failure rate
Diagram of Dimensions
Sleeve
Vent
4.0
±
0.5
2-
2
±
0.1
Unit: mm
Snap-in
Plate
L+2 Max
PC board pin-out
208
