LM0502HP Series
SMD Power Choke Coil
SMD Power Choke Coil
1. PART NO. EXPRESSION :
PIC0502HP SERIES
LM 0 5 0 2 H P 1 R 0 M F -
□□
(a)
(b)
(c)
(d)
(e)(f)
(g)
(a) Series code
(b) Dimension code
(c) Type code
(d) Inductance code : 1R0 = 1.0uH
(e) Tolerance code : M = ± 20%, Y = ± 30%
(f) F : RoHS Compliant
(g) 11~99 : Internal controlled number
2. CONFIGURATION & DIMENSIONS :
A
C
D
1R0
1151
B
E
Unit:m/m
A
5 .7± 0.3
B
5.2± 0.2
C
1.8± 0.2
D
1 .1± 0.3
E
2.5± 0.3
3. SCHEMATIC :
4. MATERIALS :
d
(a) Core : Carbonyl Powder.
(b) Wire : Polyester Wire or equivalent
(c) Solder Plating : 100% Pb free solder
(d) Ink : Halogen-free ketone
(e) Paint : Epoxy resin
e
a
b
c
5. GENERAL SPECIFICATION :
a) Test Freq. : L : 100KHz/1.0V
b) Ambient Temp. : 25° C
c) Operating Temp. : -40° C to +125° C
d) Storage Temp. : -10° C to + 40° C
e) Humidity Range : 50 ~ 60% RH (Product without taping)
f) Heat Rated Current (Irms) will cause the coil temperature rise approximately Δt of 40°C (keep 1min.)
g) Saturation Current (Isat) will cause L0 to drop 20% typical. (keep quickly).
h) Part Temperature (Ambient+Temp. Rise) : Should not exceed 125° C under worst case operating conditions.
Pb
(09/13) LM0502HP-1
20.02.2012
NOTE : Specifications subject to change without notice. Please check our website for latest information.
800.729.2099 tel
SUPERWORLD ELECTRONICS (S) PTE LTD
www.icecomponents.com
PG. 1
LM0502HP Series
SMD Power Choke Coil
SMD Power Choke Coil
6. ELECTRICAL CHARACTERISTICS :
Inductance L
( μH ) ±20%
@ 0A
0.33
0 .47
0 .68
1 .00
1 .20
1 .50
2 .20
3 .30
4 .70
5 .60
6 .80
8 .20
10
0
PIC0502HP SERIES
Part No.
LM0502HPR33MF
LM 05 02 HP R47MF
LM 05 02 HP R68MF
LM 05 02 HP 1R0MF
LM 05 02 HP 1R2MF
LM 05 02 HP 1R5MF
LM 05 02 HP 2R2MF
LM 05 02 HP 3R3MF
LM 05 02 HP 4R7MF
LM 05 02 HP 5R6MF
LM 05 02 HP 6R8MF
LM 05 02 HP 8R2MF
LM 0 502 HP1 00MF
Irms
(A)
Typ.
12
1 1.5
10
7.0
6.2
5.5
4.2
3.3
2.8
2.5
2.4
2.3
2.3
Isat
(A)
Typ.
21.3
18
1 2.8
1 3.7
1 1.0
9.8
9.0
7.3
5.0
4.0
3.8
3.5
3.4
DCR
( mΩ )
Typ. @ 25° C
6.3
7.3
11
1 7.5
23
2 6.5
4 2.0
6 6.0
1 03
1 12
1 30
1 48
1 80
DCR
( mΩ )
Max. @ 25° C
7.3
8.6
1 2.4
20
28
3 0.5
5 0.0
76
1 16
1 22
1 50
1 71
1 99
Pb
NOTE : Specifications subject to change without notice. Please check our website for latest information.
800.729.2099 tel
SUPERWORLD ELECTRONICS (S) PTE LTD
www.icecomponents.com
(09/13) LM0502HP-2
20.02.2012
PG. 2
LM0502HP Series
SMD Power Choke Coil
SMD Power Choke Coil
7. CHARACTERISTICS CURVES :
LM0502HPR33MF
TMPC0502HP
-R33
0 .6
10 0
90
80
0 .8
PIC0502HP SERIES
LM0502HPR47MF
TMPC0502HP
-R47
10 0
90
80
INDUCTANCE(uH)
TEMP. RISE(
o
C)
60
0 .3
50
40
30
0. 15
20
10
0
0
60
0 .4
50
40
30
0 .2
20
10
0
0
0
5.325
10.65
15 .975
21.3
DC CURRE
NT(A)
0
4.5
9
1 3.5
18
DC CURRE
NT(A)
1 .2
LM0502HPR68MF
TMPC0502HP
-R68
80
70
2
LM0502HP1R0MF
TMPC0502HP
-1R0
15 0
13 5
INDUCTANCE(uH)
INDUCTANCE(uH)
0 .9
60
1 .6
12 0
TEMP. RISE(
o
C)
50
0 .6
40
30
0 .3
20
10
0
0
1 .2
90
75
0 .8
60
45
0 .4
30
15
0
3. 25
6.5
9 .75
13
0
0
DC CURRE
NT(A)
0
3.425
6. 85
10 .275
13.7
DC CURRE
NT(A)
2
LM0502HP1R2MF
TMPC0502HP
-1R2
15 0
13 5
3
LM0502HP1R5MF
TMPC0502HP
-1R5
10 0
1 .6
12 0
2 .4
80
INDUCTANCE(uH)
TEMP. RISE(
o
C)
1 .2
90
75
1 .8
60
0 .8
60
45
1 .2
40
0 .4
30
15
0 .6
20
0
0
0
0
0
2. 2
4. 4
6.6
8. 8
11
DC CURRE
NT(A)
0
2
4
6
8
10
DC CURRE
NT(A)
Pb
NOTE : Specifications subject to change without notice. Please check our website for latest information.
800.729.2099 tel
SUPERWORLD ELECTRONICS (S) PTE LTD
www.icecomponents.com
(09/13) LM0502HP-3
20.02.2012
TEMP. RISE( C)
10 5
INDUCTANCE(uH)
o
TEMP. RISE(
o
C)
10 5
TEMP. RISE(
o
C)
70
INDUCTANCE(uH)
0. 45
0 .6
70
PG. 3
LM0502HP Series
SMD Power Choke Coil
SMD Power Choke Coil
7. CHARACTERISTICS CURVES :
