500-32-004 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 500-32-004

500-32-004: DescriptionRF Connector Tools SMPM M PanelRmvlTool Removal Tool; CategoryThe connector; File Size116KB，1 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/

Download Datasheet Parametric View All

500-32-004 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	500-32-004	-	-	View	Buy Now

500-32-004 Overview

RF Connector Tools SMPM M PanelRmvlTool Removal Tool

500-32-004 Parametric

Parameter Name	Attribute value
Product Category	RF Connector Tools
Manufacturer	Amphenol
Type	Extraction Tool
RF Series	SMPM
Packaging	Bag
For Use With	SMPM Male Connectors and Cable Assemblies
Material	Stainless Steel
Factory Pack Quantity	10

Preview

Download Datasheet

View All

ROHS COMPLIANT

PRODUCT DATA DRAWING

REV

REVISION HISTORY

DESCRIPTION

DATE

APPROVED

DCN 38042

03/11

STW

2.075 52.71

1.000 25.40

MATERIAL:

PUSH ROD &

PLUNGER:

BODY:

COMPRESSION

SPRING:

STAINLESS STEEL PER AMS-5640,

ALLOY UNS S30300, TYPE 1

STAINLESS STEEL PER ASTM A564,

ALLOY UNS S17400, COND. A

MUSIC WIRE

FINISH:

PUSH ROD &

PLUNGER:

BODY:

PASSIVATED PER AMS-2700

NICKEL PER SAE AMS 2404, CLASS 1

MATERIAL:

FINISH:

SEE NOTES

N/A

PROPRIETARY

DIMENSIONS ARE IN INCHES TOLERANCES:

FRACTIONAL:

DECIMAL: .X

.XX

.XXX

1/64

.030

.010

.005

ANGULAR: X

X X'

1 0'

15'

UNLESS OTHERWISE SPECIFIED

1) ALL DIMENSIONS ARE IN INCHES [MILLIMETERS]

2) ALL DIMENSIONS ARE AFTER PLATING.

3) BREAK CORNERS & EDGES .005 R. MAX.

4) CHAM. 1ST & LAST THREADS.

5) SURFACE ROUGHNESS 63

MIL-STD-10.

6) DIA.’S ON COMMON CENTERS TO BE CONCENTRIC

WITHIN .005 T.I.R.

7) REMOVE ALL BURRS

SV Microwave, Inc.

2400 Centrepark West Drive, Suite 100

West Palm Beach, FL 33409

TITLE:

SURFACE AREA:

INTERPRET DIMENSIONS AND TOLERANCES

PER ASME Y14.5M - 1994

THE INFORMATION CONTAINED IN THIS DRAWING

IS THE SOLE PROPERTY OF SV MICROWAVE, INC.

ANY REPRODUCTION IN PART OR AS A WHOLE

WITHOUT THE WRITTEN PERMISSION OF

SV MICROWAVE, INC IS PROHIBITED.

THIRD ANGLE PROJECTION

DRAWN:

CHECKED:

APPROVED:

FED 03/01/11

STW 03/01/11

SIZE CAGE CODE DWG. NO.

SMPM MALE

PANEL MOUNT

REMOVAL TOOL

95077

500-32-004

SHEET 1 OF 1

SCALE: 3:1
