SERIES 23
MIL-DTL-38999 Series III type
Sample Part Number
Series / Basic Part No.
Connector Style
Finish*
Shell Size - Insert
Arrangement*
Contact Type
Alternate Key Position*
Hermetic connectors
233-100-H8 Weld mount hermetic receptacle
How To Order Commercial
233-100
Series 23 SuperNine® Hermetic Receptacle
H8
= Weld Mount
Z1
= CRES, Passivated
ZL
= CRES, Nickel Finish
Per MIL-STD-1560
-H8
Z1
11-35
P
N
P
= Pin, Solder Cup
X
= Pin, Eyelet
C
= Pin, PCB
A, B, C, D, E, N
= Normal
S
= Socket, Solder Cup
Z
= Socket, Eyelet
D
= Socket, PCB
*Refer to Section A for complete details
Modification codes may be added directly to the end of any valid part number
D
Shell
Size
Code
A
B
C
D
E
F
G
H
J
Shell
Size
9/09
11
13
15
17
19
21
23
25
A Thread
Dimensions
ØB
.941 (23.9)
.929 (23.6)
1.063 (27.0)
1.051 (27.0)
1.189 (30.2)
1.177 (28.9)
1.315 (33.4)
1.303 (33.1)
1.402 (35.6)
1.390 (35.3)
1.547 (39.3)
1.535 (39.0)
1.689 (42.9)
1.677 (42.6)
1.854 (47.1)
1.842 (46.8)
1.941 (49.3)
1.929 (49.0)
ØC
.984 (25.0)
.972 (24.7)
1.106 (28.1)
1.094 (27.8)
1.232 (31.3)
1.220 (31.0)
1.358 (34.5)
1.346 (34.2)
1.445 (36.7)
1.433 (36.4)
1.591 (40.4)
1.579 (40.1)
1.732 (44.0)
1.720 (43.7)
1.898 (48.2)
1.886 (47.4)
1.984 (50.4)
1.972 (50.1)
ØD
.134 (3.4)
.118 (3.0)
.134 (3.4)
.118 (3.0)
.134 (3.4)
.118 (3.0)
.134 (3.4)
.118 (3.0)
.134 (3.4)
.118 (3.0)
.134 (3.4)
.118 (3.0)
.134 (3.4)
.118 (3.0)
.165 (4.2)
.149 (3.8)
.165 (4.2)
.149 (3.8)
Contact Size & Dia.
PRINTED CIRCUIT TAIL
CONFIGURATIONS
CONTACT STYLE C AND D
P
SIZE 12 AND SIZE 16
.050 ± .015
(1.27 ± 0.38)
SIZE 22D AND SIZE 20
P
.6250-.1P-.3L-TS-2A
.7500-.1P-.3L-TS-2A
.8750-.1P-.3L-TS-2A
1.0000-.1P-.3L-TS-2A
1.1875-.1P-.3L-TS-2A
1.2500-.1P-.3L-TS-2A
1.3750-.1P-.3L-TS-2A
1.5000-.1P-.3L-TS-2A
1.6250-.1P-.3L-TS-2A
Contact
Size
22D
20
16
12
øP
.011 (0.28)
.015 (0.38)
.024 (0.61)
.028 (0.71)
.0635 (1.61)
.0615 (1.56)
.095 (2.41)
.093 (2.36)
Hermetic Leak Rate Mod Codes
Designator
–585A
–585B
–585C
Required Leak Rate
1 x 10
-10
cc Helium per second
1 x 10
-9
cc Helium per second
1 x 10
-8
cc Helium per second
Wire Accommodation
Contact Size
22D
20
16
12
Wire Gauge
#22 - #28
#20 - #24
#16 - #20
#12 - #14
D-16
© 2014 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • Series 23 SuperNine® Catalog
SERIES 23
MIL-DTL-38999 Series III QPL
Sample Part Number
Series / Basic Part No.
Connector Style
Finish*
Shell Size - Insert
Arrangement*
Contact Type
Alternate Key Position*
Hermetic connectors
D38999/27 Weld mount hermetic receptacle
How To Order MS
D38999
MIL-DTL-D38999 Series III Type
/27
= Weld Mount
Y
= CRES, Passivated
N
= CRES, Nickel Finish
Per MIL-STD-1560
P
= Pin, Solder Cup
X
= Pin, Eyelet
C
= Pin, PCB Flex Feedthru
A, B, C, D, E, N
= Normal
S
= Socket, Solder Cup
Z
= Socket, Eyelet
D
= Socket, PCB
Flex Feedthru
/27
Y
B-35
P
N
*Refer to Section A for complete details
Modification codes may be added directly to the end of any valid part number
.175/.125
(4.45/3.18)
.822 (20.88)
Max
D
.071 (1.80)
.059 (1.50)
.051 (1.30)
.039 (.99)
Feedthrough
Contact (C)
D
P
Master
Keyway
øB
Solder Cup
Contact (P)
Eyelet
Contact (X)
øC
G
F
H
A
K J
B
C
E
D
A Thread
.510 (12.95) Max
Fully Mated
Indicator
Band-Red
.382 (9.7) Max for
P, X, C
.405 (10.3) Max for
S, Z, D
Consult Factory for Recommended Panel Cutout Dimensions
Mates With
Plug Part
Number
233-105SG6
Description
SuperNine® plug with single
integrated band porch
SuperNine® plug with integrated
233-105BG6
band porch and boot groove
233-105DG6
233-105-G6
SuperNine® plug with double
integrated band porch
SuperNine® plug with accessory
attachment threads
D-17
© 2014 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • Series 23 SuperNine® Catalog
