Power Dividers
True Three Way Power Division
Full 2.0 - 18.0 GHz bandwidth units
Low VSWR - High Isolation
Rugged Stripline Construction
Meets Mil-E-5400 and Mil-E16400 Environment
Three Way Isolated
Midwest Microwave's series of high performance isolatedThree Way
Power Dividers are true three way dividers. They are small, lightweight,
ruggedly constructed stripline units that possess inherently low insertion
loss and VSWR with high isolation and excellent phase and amplitude
tracking. Units are available in ultra-wideband frequency bandwidths
covering the entire range of 2.0 - 18.0 GHz. The units meet the
environmental specifications of MIL-E-5400 and MIL-E-16400.
CASE STYLE 1
CASE STYLE 2
ELECTRICAL SPECIFICATIONS
FREQUENCY
RANGE
CASE
(GHz )
STYLE
MODEL
NUMBER
AMPLITUDE
BALANCE
(dB)
0.5
0.5
0.5
PHASE
BALANCE
(degrees)
5
5
10
INSERTION
LOSS
(dB) max
1.0
1.0
1.2
ISOLATION
(dB) min
15
20
15
VSWR
max
1.50
1.50
1.80
INPUT
POWER
max(W)
5
10
10
0.5-2.0
2.0-18.0
2.0-18.0
1
2
1
PWD-5520-03-SMA-79
PWD-5532-03-SMA-79
PWD-5533-03-SMA-79
MECHANICAL SPECIFICATIONS
-
C ASE
STYLE
1
2
Note:
INCHES (mm)
A
3.00 (76.2)
2.50 (63.5)
B
0.63 (16.0)
1.25 (31.8)
C
0.250 (6.35)
0.375 (9.5)
D
1.50 (38.1)
0.75 (19.0)
E
0.080 (2.0)
0.080 (2.0)
WEIGH T
Oz
Gr
3.15
1.80
89
51
1. Specifications assume that all of the outputs are terminated with a load that has a VSWR not greater than 2.0:1.
2. TNC or NType output connectors are available by substituting "TNC" or "NNN" for "SMA" in the Model Number.
