CNX 718 Series 11/16” LED
Panel Mount Indicator
CNX 718 Series features a high intensity LED
with a wide viewing angle
Key features
• dome-shaped clear lens
• front panel mount
• 180 ° viewing angle
• .187” tab terminals
• 6” wire leads
• available in 4 voltage configurations
• RoHS compliant
Ordering data
CNX 718 11/16” indicator
ordering code (example)
Lens Type
color
N
clear
CNX 718 N X00 XX X
LED Color
color
typ intensity,
mcd
red
2800
amber
2800
green
6000
white
4900
05
12
28
120
Voltage
input voltage
5VDC
12VDC
28VDC
120VAC
Termination Style
termination style
tab terminals
T
W
wire leads
200
400
500
900
Dimensions
.62 [15.8]
.25 [6.4]
1.93 [49.0]
6.00 [152.4] min.
.50 [12.7] nom.
BLACK (–)
Ø1.0 [Ø25.5]
Ø.73 [Ø18.5]
Indicator Assembly
(wire leads)
RED (+)
11/16-27UNS-2A
NYLON HEXNUT
PLASTIC WASHER
LOCKWASHER -
ZINC PLATED STEEL
18 AWG STRANDED
UL1015 INSULATION
2.02 [51.3]
.31 [7.8]
Indicator Assembly
(tab terminals)
2X FASTON TAB
.187 SERIES
engineered to light up your design
www.vcclite.com
1.800.522.5546
10/15 Rev 2
Product Specifications
At Ambient Temperature Ta = 25°C
Output Color
Luminous Intensity Typ. (mcd) @ I
f
=20mA
Typ. Forward Current (mA) @V
f
=5VDC
Typ. Forward Current (mA) @V
f
=28VDC
Typ. Forward Current (mA) @V
f
=120VAC
Max. Forward Current (mA) @V
f
=5VDC
Max. Forward Current (mA) @V
f
=28VDC
Max. Forward Current (mA) @V
f
=120VAC
Power Dissipation (mW) @V
f
=5VDC
Power Dissipation (mW) @V
f
=28VDC
Power Dissipation (mW) @V
f
=120VAC
Peak Wavelenght (nm)
Dominant Wavelength (nm)
Operating Temperature (°C)
Storage Temperature (°C)
Reverse Breakdown @I
r
=100mA/*I
r
=50mA (V) [V
f
=5VDC]
Reverse Breakdown @I
r
=100mA/*I
r
=50mA (V) [V
f
=28VDC]
Reverse Breakdown @I
r
=100mA/*I
r
=50mA (V) [V
f
=120VAC]
Red
2800
56 ~ 69
18.5 ~ 20.5
9.3 ~ 9.8
81.0
22.5
10.7
446
675
1391
634
629
Amber
2800
56 ~ 69
18.5 ~ 20.5
9.3 ~ 9.8
81.0
22.5
10.7
446
675
1391
592
590
Green
6000
23 ~ 34
14.0 ~ 15.2
4.8 ~ 5.2
41.0
White
4900
23 ~ 34
14.0 ~ 15.2
4.8 ~ 5.2
41.0
16.5
5.6
226
495
728
-
-
16.5
5.6
226
495
728
520
525
-30 to +60
-40 to +85
5
20
270
-30 to +60
-40 to +85
5
20
270
-30 to +60
-40 to +85
*5
*10
*260
-30 to +60
-40 to +85
*5
*10
*260
• Lens is water clear with a fresnel pattern
• The Red and Amber LEDs are made from AlGaInP and Green and White LEDs are made from
GaInN.
• GaInN LEDs are class 1 ESD Sensitive (MIL-STD-1686). Use appropriate ESD precautions during
handling and operation.
Compliances and Approvals
engineered to light up your design
engineered to light up your design
www.vcclite.com
www.vcclite.com
1.800.522.5546
1.800.522.5546
10/15 Rev 2
