Series 804 Push-Pull Mighty Mouse
Spring-Loaded Cover
667-282 Ordering Information and Dimensions
X
Accessories
5
Spring-Loaded Cover for Series 804 Jam Nut Receptacles
"Flop lid" snaps shut when cable is disconnected. Silicone gasket provides watertight
seal when closed. Fits standard Series 804 rear-mount jam nut receptacles. For
.057/.067 inch (1.45/1.70 mm) panel thickness. Aluminum alloy or stainless steel.
Part Number
Shell
Size
Aluminum
Electroless
Nickel
667-282M05
667-282M06
667-282M07
667-282M08
667-282M09
667-282M10
667-282M11
667-282M12
667-282M14
667-282M15
.69 (17.5)
Stainless Steel
Black Zinc-
Nickel
667-282ZNU05
667-282ZNU06
667-282ZNU07
667-282ZNU08
667-282ZNU09
667-282ZNU10
667-282ZNU11
667-282ZNU12
667-282ZNU14
667-282ZNU15
Passivated
667-282Z105
667-282Z106
667-282Z107
667-282Z108
667-282Z109
667-282Z110
667-282Z111
667-282Z112
667-282Z114
667-282Z115
Cadmium/Olive
Drab
667-282NF05
667-282NF06
667-282NF07
667-282NF08
667-282NF09
667-282NF10
667-282NF11
667-282NF12
667-282NF14
667-282NF15
Nickel-PTFE
667-282MT05
667-282MT06
667-282MT07
667-282MT08
667-282MT09
667-282MT10
667-282MT11
667-282MT12
667-282MT14
667-282MT15
.39 (9.9)
6
7
8
9
10
11
12
14
15
.062 (1.6)
88° MIN
C
B
D
A
MARKED WITH
GLENAIR NAME
AND P/N
E
Dimensions
Shell
Size
5
6
7
8
9
10
11
12
14
15
A
In.
.63
.69
.82
.82
.88
.94
1.00
1.07
1.19
1.25
mm.
16.0
17.5
20.8
20.8
22.4
23.9
25.4
27.2
30.2
31.75
In.
.93
.99
1.11
1.11
1.18
1.24
1.30
1.36
1.49
1.55
B
mm.
23.6
25.1
28.2
28.2
30.0
31.5
33.02
34.5
37.8
39.37
In.
.251
.315
.383
.429
.485
.560
.619
.678
.801
.860
C
mm.
6.4
8.0
9.7
10.9
12.3
14.2
15.7
17.2
20.3
21.8
D Flat
In.
.427/.423
.479/.475
.606/.601
.606/.601
.667/.663
.734/.729
.801/.796
mm.
10.8/10.74
12.2/12.07
15.4/15.27
15.4/15.27
16.9/16.84
18.6/18.52
20.3/20.22
E Dia
In.
mm.
.443
11.3
.505
.630
.630
.693
.755
.820
.880
1.005
1.067
12.8
16.0
16.0
17.6
19.2
20.8
22.4
25.5
27.1
Materials and Finishes
1. Cover, Housing: Aluminum Alloy or
Stainless Steel
2. Gasket: Sponge Silicone Rubber
3. Sleeve: Delrin
4. Spring, Shaft: Stainless Steel
NOTES
.855/.851 21.7/21.62
.98/.976 24.9/24.79
1.041/1.037 26.4/26.34
Dimensions in Inches (millimeters) are subject to change without notice.
© 2014 Glenair, Inc.
Series 80 Mighty Mouse
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
X-68
E-Mail: sales@glenair.com
